High Altitude Climbing Truck 12m Hydraulic Scissor Lift Platform
High Altitude Climbing Truck 12m Hydraulic Scissor Lift Platform
Specifications
Brand Name :
KN
Model Number :
SJY
Certification :
CE,ISO
Place of Origin :
HENAN,CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
1000pcs
Delivery Time :
15 work,days
Packaging Details :
Wooden box
Certification: :
CE ISO9001
Condition: :
New
Applicable Industries: :
Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Food & Beverage Shops, Advertising Company
After Warranty Service: :
Video technical support, Online support, Spare parts
Local Service Location: :
None
Showroom Location: :
None
Place of Origin: :
HENAN, China
Lift Mechanism: :
Scissor Lift
Description

Platform Lift Clipping Fork Type Mobile Small Hydraulic Lifting Platform High-Altitude Climbing Truck

Standard Features:

With CE certification,meet EN 1570 ANSI/ASME safety standards.

Convenient electric and hydraulic system and scissor design for easy lifting,lowering.

AC 110/220/380/460V,50/60Hz power supply,low-tention (24V) control box.

Applicable to various industries,expecially in warehousing,logistics,manufacturing industies.

Custom design and specs available.

FAQ

1. Loading capacity----200KG, 250KG OR 300KG......?

2. The size of the table-----?

3. Working height------3m, 6m, 10m, 12m......?

4. Driving mode ----Diesel engine or Hydraulic or Electric or Battery ?

5. Fixed type (without wheel) or Trolley (with wheel) ?

1. The lifting platform has been inspected and debugged at the factory before delivery. All the technical indexes have reached the design requirements. When using, the lifting platform only needs to be connected with the power supply, and the hydraulic system and electrical system need not to be adjusted.

2. The platform should be carefully checked before use of hydraulic, electrical systems, no leakage or naked leakage before use.

3. Lifting platform in use, the four legs should be firmly supported on a solid ground (with the wheel to leave the ground shall prevail) if necessary, the use of sleepers.

4. Lifting platform empty run 1-3 times before loading operation.

5. load center of gravity should be as far as possible in the center of the table.

6. Guard railings at both ends of the movable door should be locked after the lock operation.

Model Lifting heig(m) Capacity(kg) Table size(mm) Power
SJY03-4 4 300 2100*820 380V/1.1KW
SJY-03-6 6 300 2100*820 380V/1.1KW
SJY-05-6 6 500 2100*820 380V/1.1KW
SJY-03-8 8 300 2100*900 380V/1.5KW
SJY-05-8 8 500 2100*900 380V/1.5KW
SJY1-8 8 1000 2100*1200 380V/3KW
SJY03-10 10 300 2100*1200 380V/2.2KW
SJY05-10 10 500 2100*1200 380V/2.2KW
SJY1-10 10 1000 2100*1500 380V/3KW
SJY03-12 12 300 2550*1500 380V/3KW
SJY05-12 12 500 2550*1500 380V/3KW
SJY1-12 12 1000 2550*1500 380V/4KW
SJY03-14 14 300 2900*1500 380V/3KW
SJY05-14 14 500 2900*1500 380V/3KW
SJY01-14 14 1000 2900*1500 380V/4KW
SJY03-16 16 300 3000*1600 380V/4KW
SJY05-16 16 500 3000*1600 380V/4KW
SJY03-18 18 300 3200*1600 380V/4KW
SJY05-18 18 500 3200*1600 380V/4KW
SJY03-20 20 300 3200*1600 380V/4KW

High Altitude Climbing Truck 12m Hydraulic Scissor Lift Platform
