Electric Forlift Truck With Steel Back Clamp Load 200 Kg Non-Standard Height 2000 Mm
Electric Forlift Truck With Steel Back Clamp Load 200 Kg Non-Standard Height 2000 Mm
Electric Forlift Truck With Steel Back Clamp Load 200 Kg Non-Standard Height 2000 Mm
Electric Forlift Truck With Steel Back Clamp Load 200 Kg Non-Standard Height 2000 Mm
Electric Forlift Truck With Steel Back Clamp Load 200 Kg Non-Standard Height 2000 Mm
Electric Forlift Truck With Steel Back Clamp Load 200 Kg Non-Standard Height 2000 Mm
Specifications
Brand Name :
YONGJIELI
Model Number :
CSD
Certification :
CE
Place of Origin :
ANHUI, CHINA
MOQ :
1 SETS
Price :
USD2470.00 - USD4700.00
Payment Terms :
L/C, T/T, D/A, D/P, Western Union
Supply Ability :
50 SETS PER MONTH
Delivery Time :
30 WORK DAYS
Packaging Details :
EXPORT PACKING
Rated Load :
200 kg
Max.Lifting Height :
4000 Kg
Arm Range :
500-1700 Mm
Lithium Batter :
25.6V160AH
Charging Voltage :
220V60HZ
Description

Non standard steel back clamp forklift
Clamping weight: 200kg
Height increase: 4000mm
Arm range: 550-1780mm
Clamp length: 1000mm
Clamp height: 800mm
Lithium battery: 25.6V160AH
Charging voltage: 220V 60Hz
Charging fork: European standard
Electronic steering pedal protection arm

Safety:

  • Curve automatic deceleration device
  • Automatic deceleration of fork in high cargo position
  • Drive stepless speed regulation
  • Controller multiple automatic protection system
  • Emergency reverse anti-collision/ emergency braking device
  • Cylinder safety shut-off valve

  • Product parameters:

Model CDD10B CDD15B
Power type Battery
Operation mode Standing type
Rated load kg 1000 1500
Load center distance mm 500
Installation level and form 2A 2A
Tire type Polyurethane
Tire specification (front wheel) mm Φ210*85
Tire specification (drive wheel) mm Φ230*75
Tire specification (multidirectional wheel) mm Φ130*55
Number of tires (front/ rear) (X= drive wheel) 2/1X+2
Mast type Duplex mast
Mast tilt angle (forward tilt/ backward tilt) (optional) ° 3/5
Standard lifting height mm 2500
Free lifting height mm /
Height of mast closed mm 1830
Height of mast open (incl. blocking rack) mm 3485
Min. ground clearance mm 70
Overall length (pedal deployment/ retraction) mm 3200/2695 3300/2795
Wheelbase mm 1200 1300
Front overhang distance mm 145
Overall width (front/ rear) mm 990/ 900
Track width (front/ rear) mm 895/ 684
Fork specifications mm 1070*100*35
Outside distance of fork mm 240-700
Channel width (1000*1200 tray) (pedal unfold/ fold) mm 3420/ 3000 3510/ 3095
Turning radius (pedal unfold/ fold) mm 1920/ 1500 2010/ 1595
Walking speed (full load/ no load) km/h 4.0/5.0
Lifting speed (full load/ no load) mm/s 80/150 77/150
Descent speed (full load/ no load) mm/s 160/105 200/105
Climbing gradient (S2-5) (full load/ no load) % 6/8 5/8
Drive motor power kw 1.5
Lifting motor power kw 2.2 3
Battery (voltage/ capacity) v/ah 24/210
Battery weight kg 200
Vehicle weight (incl. battery) kg 1815 1885
Steering type Electronic steering
Parking brake type Electromagnetic braking
Battery replacement method Lifting type
