3-10ton Single girder electric hoist overhead crane with remote control lifting equipment

Product production

Single-girder overhead crane are designed with high configuration,which is developed with advnced design technology referring to European

FEM standard. Cranes are mainly made up by electric hoist,main girder,end girder,trolleys and control rooms amd other components. This

newly developed overhead crane are with compact layout and modular structural design allows effective use of avaliable liftig height and

reduce the investment on the steel structure of workshop.

DTEH wire rope electric hoist create the greatest value for the customers with the excellent durability, high quality and

cost-effective. DTEH-01 is for single girder overhead travelling and gantry cranes.

DTEH wire rope hoist is designed and manufactured according to FEM European standard and DIN German standard, which

is a new and environment friendly product. The hoist adopts modular C-design. The product provide compact structure,

low headroom, stable lifting operation, accurate positioning. The maximum hoisting load is 20 tons.

Technical data

Features and Benefits

It employs motor of hoisting mechanism and reducer imported from Germany. The integrated and compact design of hoisting motor, reducer, reel and limit switch saves space for the user. Modular design increases the reliability of mechanism meanwhile reduces the time and cost for maintaining.

It has more and faster hoist speed and various pulley ratio which can be selected. The standard traveling mechanism of trolley is controlled by converter, with speed of 20m/min, which makes a little swing and accurate position.

1. Designed and developed with the FEM standard, advanced idea and beautiful exterior;
2. The drive units use China's advanced point-line meshing gear structure. It is easy and convenient to handle with the compact and reasonable whole structure;
3. It is safe and efficient to operate, and meet current requirements of low noise and environmental protection;
4. Using 13 proprietary technologies and utilize frequency control design to reduce the impact force to accomplish precise positioning;
5. Equipped with intelligent safe operation monitoring recorder like the "black box" on plane which can uninterruptedly record working status and prevent unprofessional operations.
6. Maintenance-free design of whole body and less wearing parts make it convenient to maintain.

Its performance reaches the international advanced level and has 11 patents protection. The whole machine adopts modular design, C structure layout. It has compact structure, stable lifting operation, accurate positioning, and the maximum weight of 80 tons. According to the structure, it can be divided with ND low clearance monorail operation and NDS double girder trolley type.

Our Service

Free maintenance: Gears (hoist and travel gearboxes) run in totally enclosed semi-fluid or oil bath lubrication, designed for the lifetime of the crane.
♦ Compact design
♦ Absolutely reliability
♦ Soft and safe acceleration, smooth operation, low noise

FAQ

Q1. Can the cranes be customized?

Yes,every customer’s working condition is different, all of our products can be customized depend on customers’ requirements. Please give us the information as clear as you can, so we can give our best design to suit for your demands.

Q2. How many operation methods for my selections?

We provide pendent controller with push button control type, remote control type or cabin control type.Please tell us what kind of operation way you need.

Q3. I have low headroom in my workshop, is it possible to install a crane in it?

We have special products for low headroom workshop, our engineer can give the best design according to your dimensions.

Q4. Do you supply lift tools?

Yes, we can provide any kind of lifting tools such as hook, electromagnetic, grab bucket etc...

Q5: In order to offer the most suitable design solution for you, it will be great helpful if you can offer us the following information to us:

1. Lifting capacity.

2. Span length.(rail center to rail center)

3. Lifting height.(hook center to ground)
