30m Wire Rope Electric Hoist 10 Ton Electric Hoist For Double Girder
30m Wire Rope Electric Hoist 10 Ton Electric Hoist For Double Girder
30m Wire Rope Electric Hoist 10 Ton Electric Hoist For Double Girder
30m Wire Rope Electric Hoist 10 Ton Electric Hoist For Double Girder
30m Wire Rope Electric Hoist 10 Ton Electric Hoist For Double Girder
30m Wire Rope Electric Hoist 10 Ton Electric Hoist For Double Girder
Specifications
Brand Name :
DONGTAI
Model Number :
DTEH-02
Certification :
ISO 9001:2016
Place of Origin :
Henan, China
MOQ :
1 Set
Price :
Negotiated
Payment Terms :
T/T, L/C
Supply Ability :
5000 sets per month
Delivery Time :
15-30 work days
Packaging Details :
Wooden case or pallet
Product Name :
30m Wire Rope Electric Hoist 10 Ton Electric Hoist For Double Girder
Keywords :
Wirerope Electric Hoist
Application :
Lifting Goods or working as overhead and gantry crane hoisting system
Capacity :
10 Ton
Power Supply :
380V, 3Phase, 50HZ
Control Method :
Pendent Control or With Remote Additional
Lifting Height :
6m-30m
Lifting Speed :
4/0.6; 3.3/0.8
Traveling Speed :
5/20
OEM :
Accept
Working Class :
FEM 2M, 3M, ISO M5, M6
Wire Rope :
∅12mm
Testing :
100% Load Test & Overload Test
Motor :
Crane Duty
Description

30m Wire Rope Electric Hoist 10 Ton Electric Hoist For Double Girder

Brief Intriduction

Electric hoist is reasonable, the brake and the motor are integrated, the safety brake is on the reel, the safety brake is not electric (completely mechanical), and it is not affected by electricity. When the brake is working normally, the safety brake does not work. When the brake fails or other parts are damaged, the weight falls, the safety brake is immediately safe and safe to ensure the safety.

The electric hoists are usually installed on single beam cranes, overhead cranes, gantry cranes, and cranes. It can greatly improve work efficiency and effectively improve labor conditions.But below 10℃ or more than 50℃is prohibited in the places where the danger of explosion is filled with sulphuric acid and other corrosive gases. It is prohibited to use this product in the places where the toxic substances are suspended, in order to ensure the safety and reliability of the operation. Recommending the use of remote control for new electric hoists.

30m Wire Rope Electric Hoist 10 Ton Electric Hoist For Double Girder

30m Wire Rope Electric Hoist 10 Ton Electric Hoist For Double Girder

30m Wire Rope Electric Hoist 10 Ton Electric Hoist For Double Girder

Technical Data

Capacity ton Lifting height m Lifting speed m/min Lifting motor kw Lifting System FEM/ISO
3.2t 6/9/12/15/18 5/0.8 3.2/0.42 2M M5
5t 6/9/12/15/18 5/0.8 6.1/1 2M M5
6.3t 6/9/12/15/18 5/0.8 6.1/1 2M M5
8t 6/9/12/15/18 5/0.8 9.5/1.5 2M M5
10t 6/9/12/15/18 5/0.8 9.5/1.5 2M M5
12.5t 6/9/12/15/18 5/0.8 12.5/2 1AM M4
16t 6/9/12/15/18 4/0.6 16/2.6 2M M5
20t 6/9/12/15/18 4/0.6 16/2.6 1Am M4
20t 6/9/12/15/18 4/0.6 16/2.6 1Am M4
25t 6/9/12/15/18 3.3/0.8 20/5 3M M6
25t 6/9/12/15/18 3.3/0.8 20/5 3M M6
32t 6/9/12/15/18 3.3/0.8 20/5 2M M5
32t 6/9/12/15/18 3.3/0.8 20/5 2M M5

Features and Benefits

It employs motor of hoisting mechanism and reducer imported from Germany. The integrated and compact design of hoisting motor, reducer, reel and limit switch saves space for the user. Modular design increases the reliability of mechanism meanwhile reduces the time and cost for maintaining.

It has more and faster hoist speed and various pulley ratio which can be selected. The standard traveling mechanism of trolley is controlled by converter, with speed of 20m/min, which makes a little swing and accurate position.

Advantage

1. Full Variable frequency drive- Energy Saving

2. Protection class IP54- Long Life

3. Noise as low as 65 decibels- Mute

4. High Level of work- High Efficiency

5.Built in precision planetary reducer drive- Safe and Efficient

Safety Device

Safety is the most important issue for metallurgical cu electric hoist for steel casting. To ensure the safety, we equip the
following safety devices:
1. Weight overload protection device
2. Lifting height limit device
3. Voltage lower protection function
4. Phase sequence protection function
5. Emergency stop function
6. Rain cover for outside hoist, driving units, electrical cubicle
7. Warming indicator, flashing lights and warming sound
8. Wireless infra-detector for anti-collusion

Tags:Wire Rope Hoist, Electric Hoist, Hoist for Double Girder
