Irrigation Deep Well Submersible Water Pump , 3 Inch Submersible Water Well Pump
Irrigation Deep Well Submersible Water Pump , 3 Inch Submersible Water Well Pump
Irrigation Deep Well Submersible Water Pump , 3 Inch Submersible Water Well Pump
Irrigation Deep Well Submersible Water Pump , 3 Inch Submersible Water Well Pump
Irrigation Deep Well Submersible Water Pump , 3 Inch Submersible Water Well Pump
Irrigation Deep Well Submersible Water Pump , 3 Inch Submersible Water Well Pump
Irrigation Deep Well Submersible Water Pump , 3 Inch Submersible Water Well Pump
Irrigation Deep Well Submersible Water Pump , 3 Inch Submersible Water Well Pump
Irrigation Deep Well Submersible Water Pump , 3 Inch Submersible Water Well Pump
Irrigation Deep Well Submersible Water Pump , 3 Inch Submersible Water Well Pump
Specifications
Brand Name :
Aier
Model Number :
QJ
Place of Origin :
Hebei, China
MOQ :
1
Payment Terms :
T/T, L/C
Supply Ability :
200 sets per month
Delivery Time :
25-60 days
Packaging Details :
wooden case
Material :
stainless steel 304, 316, Cast iron
structure :
Multistage
Power :
electric
Application :
Power plant dam dewatering, mining dewatering, irrigation, water supply, drainage
Certification :
ISO9001
Voltage :
380/400/440/660
Description

Irrigation deep well submersible pump with large flow capacity for deep well or borehole well

Product introduction:

1. QJ multistage deep well submersible pump bore hole pump is simple structure, easy installation, convenient operation and maintenance.

2. Pump is equipped with inner motor, and special designed for whole submerge work. (Electrical machine and pump wok as a whole, it's safe very much.)

3. It is suitable to transport water for extraction of deep groundwater, can also be used in deep well, rivers, reservoirs and ditch water projects.

4. The bore hole pump is mainly used for irrigation and livestock water system, also for city, factory, railways, mining, water supply and drainage construction site.

5. Stainless steel submersible pump for models less than DN100mm(4inch) and cast iron pumps for models with larger diameter.

Product details:

Working Principle: Submersible, Multi-stage
Main applications: Water
Driver: Electric motor
Power Specs: 220/380/415V 3phase; 110/220/240V 1phase, 50hz/60hz
Max.permissible fluid temperature: 90°C
Type of connection: Flange
Installation position: Vertical
Casing/Inner parts material: Cast iron,Stainless steel /Cast iron, Stainless steel
Shaft seal type: Mechanical seal
Free passage: 0.1 mm
Maximum drive rating: 260KW
Maximum discharge caliber: 300mm
Maximum discharge-side pressure: 2.8MPa
Maximum head: 1500m
Flow rate range: 5-600m3/h

Performance data:

Model Capacity Head Speed Efficiency Power Current Base DN
(m³/h) (L/s) (m) (r/min) (%) (KW) (A) (mm)
… ...
300QJ250-20/1 250 69.4 20 2900 76 18.5 43.6 281
300QJ250-40/2 40 37 82.6
300QJ250-60/3 60 55 118.4
300QJ250-80/4 80 75 158.7
300QJ250-100/5 100 90 185
300QJ250-120/6 120 110 220.8
300QJ250-140/7 140 125 249.5
300QJ250-160/8 160 140 277.8
300QJ250-180/9 180 160 317.5
300QJ250-200/10 200 185 367.1
300QJ300-15.5/1 300 83.3 15.5 2900 76 18.5 43.6 281
300QJ300-31/2 31 37 82.6
300QJ300-46.5/3 46.5 55 118.4
300QJ300-62/4 62 75 158.7
300QJ300-77.5/5 77.5 90 185
300QJ300-93/6 93 110 220.8
300QJ300-108.5/7 109 125 249.5
300QJ300-124/8 124 140 277.8
300QJ300-139.5/9 140 160 317.5
300QJ300-155/10 155 185 367.1

Irrigation Deep Well Submersible Water Pump , 3 Inch Submersible Water Well PumpIrrigation Deep Well Submersible Water Pump , 3 Inch Submersible Water Well Pump
