Aier Borehole Submersible Water Pumps , Vertical Submersible Pump Electric Power
Aier Borehole Submersible Water Pumps , Vertical Submersible Pump Electric Power
Aier Borehole Submersible Water Pumps , Vertical Submersible Pump Electric Power
Aier Borehole Submersible Water Pumps , Vertical Submersible Pump Electric Power
Aier Borehole Submersible Water Pumps , Vertical Submersible Pump Electric Power
Aier Borehole Submersible Water Pumps , Vertical Submersible Pump Electric Power
Aier Borehole Submersible Water Pumps , Vertical Submersible Pump Electric Power
Aier Borehole Submersible Water Pumps , Vertical Submersible Pump Electric Power
Specifications
Brand Name :
Aier
Model Number :
QJ,QS
Place of Origin :
Hebei,China
MOQ :
1
Payment Terms :
T/T, L/C
Supply Ability :
300 units per month
Delivery Time :
20-60days
Packaging Details :
wooden case
wet partsMaterial :
Cast iron or stainless steel
structure :
multistage vertical
Application :
irrigation, ming dewatering, water supply
Power :
Electric
Certification :
CE, ISO9001
Flow rate :
5 - 1000 m3/h
Description

Agricultural irrigation submersible borehole pump for water supply, dewatering, head from 5 to 1000 m

Product Application

Agricultural irrigation submersible bore hole pump is vertical single suction multi-stage submersible pump.Pump and motor is an organic whole repeatedly, into the water, this series of pump is the main tool, deep well water use for urban and rural areas, industrial and mining enterprises and agricultural irrigation water.

Size 6" 7" 8" 9" 10" 11" 12"
Head Range Flow Range Motor Power Outlets range
m m³/h kw mm
150QJ 600-18 5-63 2.2-18.5 40-75
175QJ 273-9 5-80 3-37 40-120
200QJ 405-15 15-100 3-55 50-90
250QJ 320-20 50-160 5.5-110 80-150
300QJ 240-20 200-500 18.5-220 150-200
BEISIDES
350QJ 300-60 320 90-410
400QJ 150-50 400-600 90-410

Materials:

Delivery casing:

1, non-corrosive medium: cast iron HT200;

2, mildly corrosive medium: anticorrosive coating, chemical treatment; moderately corrosive medium: stainless steel 304;

3, strongly corrosive medium: stainless steel 316, stainless steel 316L,

tin bronze 3861.

Deep well Submersible pump tech parameter :

a) Outlet : DN150 - DN400 mm
b) Flow rate: 5-1000 cubic meter per hour
c) Head : 10-1000 m
d) Speed : 1450 - 2850r/min
e) Rated power : 3-500 KW
f) Working condition temperature: -15℃ - 100 ℃

g) Power voltage: 380/440/660

Frequency: 50HZ/60HZAier Borehole Submersible Water Pumps , Vertical Submersible Pump Electric PowerAier Borehole Submersible Water Pumps , Vertical Submersible Pump Electric Power
