ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
Specifications
Brand Name :
NORGREN
Model Number :
SXE9575-A71-00/13J
Place of Origin :
UK
MOQ :
1
Price :
contact
Payment Terms :
TT
Supply Ability :
100unit / month
Delivery Time :
15 days
MODEL :
SXE9575-A71-00-13J
Material :
cast aluminium
Flow rate :
4400 l/min
Size :
22mm ISO #3
Brand :
Norgren
voltage :
24Vdc
Standard :
ISO 5599-1
Pressure :
16.0 bar
Description

ISO STAR solenoid valve SXE9575-A71-00/13J control part IMI NORGREN cast aluminium

ISO Star electric control valve - solenoid pilot

characteristic

·The valve core and valve sleeve with special coating metal seal can work without fault and long life

·Iso#1 and iso#2 valves with integral flow regulating valve

·Standard low power solenoid with manual control

·Rich base plate and accessories

Product: sxe9575-a71-00-13j

Flow:4400 l/min

ISO size: ISO #3

drive: forty-one thousand and thirty-one

Standard: ISO 5599-1; VDMA 24 345

Brand: ISO*STAR

voltage: 24Vdc

junction box type: 22mm industrial standard

Medium: Compressed air 41031

drive Start: : Electric control / air spring

voltage: 24Vdc

maximum working pressure: 16.0 bar

working pressure: 1 ... 10 bar

working temperature: -15 ... 80 °C

ISO size: ISO #3

electrical connection: 22mm industrial standard

pilot: Inside

manual control: VDMA 24 345 ; Locking device

protection grade: IP65

Standard: ISO 5599-1

flow: 4400 l/min

junction box type: 22mm industrial standard

coil power: 2.0 Watt/VAC

material - nut and screw: Galvanized steel Nitrile rubber; Heat resistant seal

Seal: Body: Die cast aluminum

valve core and sleeve: Anodized aluminum

Brand:ISO*STAR

ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
