5M Tesla Charger Cable AC 32A 40A 50A 60A 80A EV Charger Accessories
5M Tesla Charger Cable AC 32A 40A 50A 60A 80A EV Charger Accessories
5M Tesla Charger Cable AC 32A 40A 50A 60A 80A EV Charger Accessories
5M Tesla Charger Cable AC 32A 40A 50A 60A 80A EV Charger Accessories
5M Tesla Charger Cable AC 32A 40A 50A 60A 80A EV Charger Accessories
5M Tesla Charger Cable AC 32A 40A 50A 60A 80A EV Charger Accessories
5M Tesla Charger Cable AC 32A 40A 50A 60A 80A EV Charger Accessories
5M Tesla Charger Cable AC 32A 40A 50A 60A 80A EV Charger Accessories
Specifications
Brand Name :
Evoyage
Model Number :
EV32AP
Place of Origin :
Sichuan, China
MOQ :
1 pieces
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, Paypal, Alipay, Cash
Supply Ability :
10000 Piece/Pieces per Week
Delivery Time :
7-15 Working days
Packaging Details :
40 x 40 x 50 cm;20.000 kg
Product Name :
AC 32A/40A/50A/60A/80A Tesla Charger Cable| 5M Cable | Compatible with Model 3/Y/S/X | EV Charging Accessory
Rated current :
32A/40A/50A/60A/80A
Rated voltage :
AC 120V / AC 240V
Standard :
Tesla/NACS
Description

AC 32A/40A/50A/60A/80A Tesla Charger Cable| 5M Cable | Compatible with Model 3/Y/S/X | EV Charging Accessory

5M Tesla Charger Cable AC 32A 40A 50A 60A 80A EV Charger Accessories

32A 50A NACS EV Connector for Level 2 EV Charging

  • Rated current: 32A/40A/50A/60A/80A
  • Rated voltage: 110V/240V AC
  • Operation Temp.:-30℃ ~ + 50℃
  • IP protection class: IP 55 ( working condition)
  • Product description: Our new NACS AC charging cables, customizable to fit all your charging needs. Whether you are looking for 32A, 40A, 50A,60A or 80A options, we have you covered. Our NACS AC charging cables are designed fo

5M Tesla Charger Cable AC 32A 40A 50A 60A 80A EV Charger Accessories
  • Features

Charging plug meeting Tesla NACS standard

Housing massive structure promote protection performance

Product entire insertion and extraction force<90N

Protection class IP55

  • Mechanical properties

Mechanical life:no-load plug in/pull out>10000 times

Impact of external force:can afford 1M drop and 2t vehicle run over pressure

  • Applied Materials

Case Material:Thermoplastic,flame retardant grade UL94V-0

Contact bush:Copper alloy,silver plating

UV Resistance:F1 per UL 746C

Product Parameters:

Product Tesla AC Plug with Cable
Product Model EVO-TSA-32A , EVO-TSA-40A , EVO-TSA-50A, EVO-TSA-60A,FV-TSA-80A Terminal Rise ＜50K
Rated Current 32A /40A/50A/60A/80A Operating Temperature -30°C~+50°C
Operation Voltage AC 120V / AC 240V Impact Insertion Force >300N
Insulation Resistance ＞1000MΩ(DC 500V) Waterproof Degree IP55
Withstand Voltage 2000V Cable Color Black ,Orange, Green, Blue etc.
Pin Material Copper Alloy, Silver Plating Cable Length (5Meter ,10Meter) The length of the cable can be customized
Shell Material Thermoplastic,Flame Retardant Grade UL94 V-0 Cable Protection Reliability of materials, anti-flaming, pressure-resistant, abrasion resistance
Mechanical Life No-Load Plug In / Pull Out ＞10000 Times impact resistance
Contact Resistance 0.5mΩ Max Certification UL,TUV,CE Approved
Rated Current Cable Specifications
32A 3 X 10AWG + 1 X 18AWG
50A 2 X 8AWG + 1 X 10AWG + 2 X 16AWG
80A 2 X 5AWG + 1 X 8AWG + 6 X 20AWG
