SAE J1772 EV Connector 16A 32A 40A 50A Type 1 EV Plug For US Standard Electric Vehicle Charging Station EV Cable Plug
SAE J1772 EV Connector 16A 32A 40A 50A Type 1 EV Plug For US Standard Electric Vehicle Charging Station EV Cable Plug
SAE J1772 EV Connector 16A 32A 40A 50A Type 1 EV Plug For US Standard Electric Vehicle Charging Station EV Cable Plug
SAE J1772 EV Connector 16A 32A 40A 50A Type 1 EV Plug For US Standard Electric Vehicle Charging Station EV Cable Plug
SAE J1772 EV Connector 16A 32A 40A 50A Type 1 EV Plug For US Standard Electric Vehicle Charging Station EV Cable Plug
SAE J1772 EV Connector 16A 32A 40A 50A Type 1 EV Plug For US Standard Electric Vehicle Charging Station EV Cable Plug
SAE J1772 EV Connector 16A 32A 40A 50A Type 1 EV Plug For US Standard Electric Vehicle Charging Station EV Cable Plug
SAE J1772 EV Connector 16A 32A 40A 50A Type 1 EV Plug For US Standard Electric Vehicle Charging Station EV Cable Plug
Specifications
Brand Name :
Evoyage
Model Number :
EV32AP
Place of Origin :
Sichuan, China
MOQ :
1 pieces
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, Paypal, Alipay, Cash
Supply Ability :
10000 Piece/Pieces per Week
Delivery Time :
7-15 Working days
Packaging Details :
18.5X14.5X9 cm;1.000 kg
Product Name :
EV Car Charger Plug SAE J1772 Connector Type 1 16A 3.5KW 32A 7KW for Electric Vehicle Charging Station EVSE Wallbox
Rated current :
16A / 32A
Rated voltage :
110V-250V
Standard :
SAE J1772/Type1
Cable :
black with TPU jacket. Other color optional by customizing
Shell :
white/ black by thermoplastic PC
Phase :
1
Warranty :
1 Year
Description

SAE J1772 EV Connector 16A 32A 40A 50A Type 1 EV Plug For US Standard Electric Vehicle Charging Station EV Cable Plug

SAE J1772 EV Connector 16A 32A 40A 50A Type 1 EV Plug For US Standard Electric Vehicle Charging Station EV Cable Plug

Electric Performance:

Protection rank: IP65

Fire retardant level: 94 V-0

Rated Current: 16A/32A/40A/50A

Rated voltage: 110V / 250V

Insulation resistance: > 1000M ohm (DC 500V)

Terminal temperature rise: <50K

Withstand voltage: 2000V

Contact resistance: 0.5m ohm Max

Coupled insertion force: >45N <80N

Operating temperature: -30C to 50C

Mechanical Testing

Mechanical life: no load plug in / pull out > 10000 times

Impact of external force: qualify 1m drop or 2 Ton vehicle run over

Materials Applied

Connector: by copper alloy with nickel bottom plating and 3um silver surface plating

Shell: white/ black by thermoplastic PC. Fire retardant. Other color optional by customizing

Cable: black with TPU jacket. Other color optional by customizing

SAE J1772 EV Connector 16A 32A 40A 50A Type 1 EV Plug For US Standard Electric Vehicle Charging Station EV Cable Plug

SAE J1772 EV Connector 16A 32A 40A 50A Type 1 EV Plug For US Standard Electric Vehicle Charging Station EV Cable Plug

 SAE J1772 EV Connector 16A 32A 40A 50A Type 1 EV Plug For US Standard Electric Vehicle Charging Station EV Cable Plug

Charge Quickly

level 1 EV charger charges your vehicle quickly and effortless.

J1772 Level 1 EV Charger

This EV charger fits most EVs & PHEVs, can charge any type 1 (SAE J1722) vehicle. Tesla needs adapter, otherwise this electric car charger is not suitable for tasla.

Total 5M

Whether you have a garage or need to charge outdoors, the total 5M charging cable provides all the options for your daily use.

This SAE J1772 EV connector EV plug can be assembled with UL listed cable. The maximum power provided from the plug is from 16A up to 32A, 40A, 50A. It is usually used for type 1 Electric Vehicle charging staion car side cable or level 2 portable ev chargers.

The Wallbox or Portable EV chargers with SAE J1772 /Type 1 EV cable connector is compatible with all the US standard cars it is called Type 1 electric vehicles like: Citroen C-Zero, Ford Focus Electric, Mitsubishi Outlander PHEV, Kia Soul EV, Nissan Leaf 2012 – 2017, Peugeot (uses both types), Toyota Prius, Vauxhall, etc.

SAE J1772 EV Connector 16A 32A 40A 50A Type 1 EV Plug For US Standard Electric Vehicle Charging Station EV Cable Plug

SAE J1772 EV Connector 16A 32A 40A 50A Type 1 EV Plug For US Standard Electric Vehicle Charging Station EV Cable Plug

SAE J1772 EV Connector 16A 32A 40A 50A Type 1 EV Plug For US Standard Electric Vehicle Charging Station EV Cable Plug
