QMFD5200Wheeled fan dui jiPull rod control type
QMFD5200Wheeled fan dui jiPull rod control type
Specifications
Brand Name :
QIMENG
Model Number :
QMFD5200
Certification :
MAKA
Place of Origin :
Zhengzhou City
MOQ :
One set
Price :
Negotiable
Payment Terms :
L/C
Supply Ability :
fifteen set per month
Delivery Time :
15-30 work days
Packaging Details :
Wooden box
Heap width :
5200mm
Heap height :
2200mm
other name :
QMFD5200Wheeled fan dui ji
Working speed :
0—18m/min
Machine weight :
10500kg
Overall size :
5.8m×3.4m×3.9m
Description

QMFD5200Wheeled fan dui ji

Performance features:

QMFD-5200 pull rod Operating Type: (no steering wheel) material fermentation tipper eliminates hydraulic steering wheel tipper.It is a new product produced by our company.It fills a blank that the domestic large wheel-type tipper can't turn around in the same place.Without the steering wheel, the driver only needs to easily control the two pull rods, then the tipper can realize the brake of turning left and right and the turn of 180 degrees in situ, and the hydraulic balance of the steering wheel.The height of the turn-over shaft can automatically rise and fall, and the forced turn-over can be chosen according to the moisture content of the material, and the turn-over can be performed at high speed.This product adopts soft start to turn over and clutch, (domestic similar products all adopt iron-to-iron clutch, which causes serious damage to chains, bearings andaxles) and is equipped with front hydraulic push plate, which does not need to take time and time for the whole pile. Roller hydraulic lift. It greatly saves the site, time, diesel and manpower, and advances the fermentation period.

Type of tipper QMFD-5200Mechanical track type tipper
Heap width 5200mm
Heap height 2200mm
Row spacing of deposits 0.8-1m
Maximum diameter of material particles φ250mm
Power 194kwDiesel engine

Torque

 1100N.m
Rated power speed per hour 2200r/min
Working speed 0-18m/min
Driving speed 50m/min
Processing capability 2500-2800m³/h
Overall size 5.8m×3.4m×3.9m
Machine weight 10500kg
