Specifications
Brand Name :
Analog Devices Inc.
Model Number :
AD5304ARMZ-REEL7
Certification :
ISO9001
Place of Origin :
China,GuangDong
MOQ :
>=10pcs
Price :
$4.39
Payment Terms :
L/C, D/A, D/P, Western Union, T/T,
Supply Ability :
10000 Acre/Acres per Day+pcs+1-2days
Delivery Time :
2-3work days
Packaging Details :
Original factory sealed packing with standard types: tube,tray,tape and reel,box,bag packing.
Description :
IC DAC 8BIT V-OUT 10MSOP
Package / Case :
10-TFSOP
Mounting Type :
Surface Mount
Operating Temperature :
-40°C ~ 105°C
Voltage - Supply :
2.5V ~ 5.5V
Type :
Voltage - Buffered
Product Status :
Active
Base Product Number :
AD5304
Description

Integrated Circuits AD5304ARMZ-REEL7 8 Bit Digital To Analog Converter 4 10-MSOP

PRODUCT DESCRIPTION


The AD5304/AD5314/AD53241 are quad 8-, 10-, and 12-bit buffered voltage output DACs in 10-lead MSOP and 10-lead LFCSP packages that operate from a single 2.5 V to 5.5 V supply, consuming 500 μA at 3 V.

Their on-chip output amplifiers allow rail-to-rail output swing to be achieved with a slew rate of 0.7 V/μs. A 3-wire serial interface is used; it operates at clock rates up to 30 MHz and is compatible with standard SPI, QSPI, MICROWIRE, and DSP interface standards.

The references for the four DACs are derived from one reference pin. The outputs of all DACs can be updated simultaneously using the software LDAC function.

The parts incorporate a power-on reset circuit, and ensure that the DAC outputs power up to 0 V and remains there until a valid write takes place to the device. The parts contain a power-down feature that reduces the current consumption of the device to 200 nA @ 5 V (80 nA @ 3 V).

The low power consumption of these parts in normal operation makes them ideally suited to portable battery-operated equipment. The power consumption is 3 mW at 5 V, 1.5 mW at 3 V, reducing to 1 μW in power-down mode.

PRODUCT PROPERTIES

Product Status
Active
Number of Bits
8
Number of D/A Converters
4
Settling Time
8µs
Output Type
Voltage - Buffered
Differential Output
No
Data Interface
SPI, DSP
Reference Type
External
Voltage - Supply, Analog
2.5V ~ 5.5V
Voltage - Supply, Digital
2.5V ~ 5.5V
INL/DNL (LSB)
±0.15, ±0.02
Architecture
String DAC
Operating Temperature
-40°C ~ 105°C
Package / Case
10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Supplier Device Package
10-MSOP
Mounting Type
Surface Mount
Base Product Number
AD5304

Integrated Circuits AD5304ARMZ-REEL7 8 Bit Digital to Analog Converter 4 10-MSOP

Integrated Circuits AD5304ARMZ-REEL7 8 Bit Digital to Analog Converter 4 10-MSOP
Integrated Circuits AD5304ARMZ-REEL7 8 Bit Digital to Analog Converter 4 10-MSOP
