60 Ton Rated Load Truck Weighbridge 10mm Thickness Perfect Detection Means
60 Ton Rated Load Truck Weighbridge 10mm Thickness Perfect Detection Means
Specifications
Brand Name :
Pinglei
Model Number :
SCS
Certification :
ISO9001
Place of Origin :
Hebei
MOQ :
1 Set
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100 Sets Per Week
Delivery Time :
10 Days
Packaging Details :
Bulk
Platform Size :
3*9m
Rated Load :
60 Tons
Accuracy :
20kg
Material :
Steel Plate, "U" Steel
Length Available :
6M, 9M, 12M, 16M, 18M, 24M
thickness :
8mm / 10mm
Description

60 Ton Rated Load Truck Weighbridge 10mm Thickness Perfect Detection Means

Our company is focused on quality and development of the structures, so that

we can control the cost for the customers, as well as having great technical support.

Perfect detection means

100% before delivery performance calibration

Excellent quality control team

Innovative high reliability scale body

Open end installation structure

High quality U steel girders

Horizontal reinforced bar arrangement way

The most advanced automated production equipment

Overall shot blasting derusting, eliminate all sorts of stress

Digital cutting

Automated continuous welding

High temperature of the lacquer that bake, more resistant to corrosion

First-class design and evaluation of the team

The entire Solidworks software design

It is middle dissected,with a top cover on the platform for access to the loadcells.

Specifications:Width:3m 3.2m 3.4mLength:5m,6m,7m,8m,9m,10m,12m,14m,15m,16m,18m,20m,21m,24mAccuracy:IIICapacity:10t~200t

Platform

W x L (m)

 Module Qty Description
SCS-30 SCS-50 SCS-60 SCS-80 SCS-100 SCS-120 SCS-150 SCS-200
3X7 3.4X7 1 V V V
3X10 3.4X10 2 V V V
3X12 3.4X12 2 V V V V V V
3X15 3.4X15 3 V V V V V
3X16 3.4X16 3 V V V V V V
3X18 3.4X18 3 V V V V V V V
3X20 3.4X20 4 V V V V V
3X21 3.4X21 4 V V V V V
3X22 3.4X22 4 V V V V V
3X24 3.4X24 4 V V V V V
Max capacity(t) 30 50 60 80 100 120 150 200
Division(kg) 10 20 20 20 50 50 50 50
Load cell capacity(t) 20 25 25 40/45 40/45 45/60 60 90
Precision OIML III
Working temperature Indicator -10℃~ +40℃
Load cell -30℃~ +65℃
Humidity relative ≤95% (without dew)
Working power Voltage 220VAC(-15%~+10%)/50±1Hz


60 Ton Rated Load Truck Weighbridge 10mm Thickness Perfect Detection Means
