Truck scale Accuracy 20 kg Rated Load 120 ton Power Supply AC 220V / 50Hz
Truck scale Accuracy 20 kg Rated Load 120 ton Power Supply AC 220V / 50Hz
Specifications
Brand Name :
Pinglei
Model Number :
SCS
Certification :
ISO9001
Place of Origin :
HEBEI
MOQ :
5sets
Price :
negotiation
Supply Ability :
1000 Sets Per Week
Delivery Time :
10 Day
Packaging Details :
Paper Carton
Type :
Livestock Scale
weighing body :
6-8 main longitudinal girders
welding skill :
fifth generation U-shape section welding
steel plate surface :
epoxy zinc rich primer and acrylic marine paint
internal cavity :
omniseal and anticorrosion
load cell protection :
IP68
Description

Truck scale Accuracy 20 kg Rated Load 120 ton Power Supply AC 220V / 50Hz

Technical parameters:
Truck scale width: 3m 3.2m 3.4m

Truck scale length: 6m 7m 8m 9m 10m 12m 14m 16m

Weighing scope: 1t~50t
Accuracy class: OIML III

Converting speed: A/D, 500 Times/SEC
Weighing way: vehicle or axis measurement
Load cell: excitation voltage +10V
Remote transmission characteristics: no influence within 100 meters
Environmental temperature: load cell, -20 - +40°C;
weighing indicator: 0 - +40°C
Environmental humidity: <90% RH, without dew
Power supply: 220V(AC)+10%, 50Hz; 12V(DC), 500mA
Rated power: <20W
Display mode: 6 fluorescence display,
16 matrix liquid crystal display
Indicator keyboard: skin type 25 key keyboard
Communication interface: Rs232c can be connected to the printer or computer;
Rs422 communication interface is optional.
Control output: be able to expand 3 control output
Data storage: 384 weighing record
Data protection: real-time clock, data protection in blackout
Cable length: 30m signal cable
Indicator shell: aluminum closed shell,
338 x 200 x 220 mm

Weighing platform material: flatbed or diamond plate (optional)

Truck scale Accuracy 20 kg Rated Load 120 ton Power Supply AC 220V / 50Hz
