3 Ton Industrial Floor Pallet Scale , Mobile Truck Scales Labor Saving
3 Ton Industrial Floor Pallet Scale , Mobile Truck Scales Labor Saving
Specifications
Brand Name :
Pinglei
Model Number :
SCS
Certification :
ISO9001
Place of Origin :
Hebei
MOQ :
5sets
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5000 Sets Per Week
Delivery Time :
10 day
Packaging Details :
Paper Carton with Pallet
Dimension :
0.8mX0.8X0.11m ~ 2mX3mX0.13m
Capacity :
0.5t ~ 10t
Rated Load :
3 ton
Height :
10cm, 11cm
Steel Plate Type :
Plain Plate or Checker Plate
Load Cell :
4pc
Description

3 Ton Electronic Industrial Floor Scale Platform Weighing Scale

1. Pit-less Type Platform Scale Series

Carbon steel/ SST pit-less type platform scale: checked iron surface plate(surface plate of SST models is smooth plate) combined with serried channel steel girder formed a higher strength and reliable platform scale. Low height design make load and unload by forklift convenient.

Dimension: 0.8mX0.8X0.11m ~ 2mX3mX0.13m

Capacity:0 .5t ~ 10t

2. Pit Type Platform Scale Series

Carbon steel/ SST pit type platform scale: checked iron surface plate(surface plate of SST model is smooth plate) combined with serried channel steel girder formed a higher strength and reliable platform scale. No parts of scale extend above the ground level, all kinds of loading and unload by trolley, pallet truck and forklift could be done without hindrance.

Dimension: 0.8mX0.8X0.09m ~ 2mX3mX0.13m

Capacity: 0.5t ~ 10t

3. Low Profile Platform Scale Series

Carbon/SST ultra low height design platform scale, checked iron surface plate. The non-integral design between scale structure and ramps could protect load cell efficiently. The overall height of the surface plate is only 5cm which is pretty easy for trolley to load and unload products.

Dimension: 0.8mX0.8X0.04m ~1.5mX1.5mX0.05m

Capacity: 0.3t-2t

4. Movable Scale Series

Carbon/Stainless moveable weighing scale, with four wheels which can be adjusted up and down by a handle, applied to places where weighing position is not fixed, time-saving and labor-saving.

Dimension: 0.8mX0.8X0.04m ~2mX2mX0.05m

Capacity: 1t~5t

Panel Size

Panel Thickness

Product Weight

Height

Capacity

0.8m*0.8m

4mm~6mm

60KG

10CM

1Ton~3Ton

1.0m*1.2m

4mm~6mm

90KG

10CM

1Ton~3Ton

1.2m*1.5m

4mm~6mm

130KG

10CM

1Ton~3Ton

1.5m*2.0m

4mm~6mm

200KG

10CM

1Ton~5Ton

2.0m*2.0m

4mm~10mm

285KG

11CM

1Ton~3Ton

2.0m*3.0m

4mm~10mm

410KG

11CM

1Ton~3Ton

Remark:The panel size and capacity can be customized.
