SCS-120t 3*18m 120t Electronic Lorry Weighbridge Truck Weighing Systems High Accuracy
SCS-120t 3*18m 120t Electronic Lorry Weighbridge Truck Weighing Systems High Accuracy
Specifications
Brand Name :
PINGLEI
Model Number :
SCS
Certification :
ISO9001
Place of Origin :
SHIJIAZHUANG
MOQ :
1SET
Price :
NEGOTIATION
Payment Terms :
L/C, T/T
Supply Ability :
15SETS PER WEEK
Delivery Time :
15DAYS
Packaging Details :
IN BULK
Power Supply :
220V/50HZ, Voltage 220VAC
Color :
White, grey, green or according
Battery :
6V/4AH Rechargeable
Load cell capacity :
120%
Accuracy :
30KGS
Display Type :
LED
Description

Features:

1. Plain plate or chequered plate optional

2. From side to access to the load cell

3. Middle dissected, with bolts connection

4. Composed of 4 or 6 U beams and C channel beams, robust and rigid.

5. Double shear beam load cell or column load cell selectable

6. Easy assembly and installation

7. Pit & pitless mounted alternatively, and pitless mounted more often

8. Side rails optional (preventing trucks from slipping from the platform)

Specifications:

Width available

3m, 3.2m, 3.4m

Length available

6m,7m,8m,9m,10m,12m,14m,16m,18m,20m,21m,24m, customized

Accuracy grade

Class III

Max. Cap.

10t~200t

truck scale Size for your reference:

Dimension

Modules

Capacity

mxm

t

3x6

2 pcs 1.5*6m

30~60

3x7

2 pcs 1.5*7m

30~60

3x9

4 pcs 1.5*4.5m

60~80

3x10

4 pcs 1.5*5m

60~80

3x12

4 pcs 1.5*6m

60~120

3x15

6 pcs 1.5*5m

60~120

3x16

6 pcs 1.5*5.33m

60~120

3x18

6pcs 1.5*6m

60~120

3x20

8pcs 1.5*5m

60~120

Technical information:

Weigh Accurate Grade: OIML III

Working Environment Humidity: ≤95%

Working Temperature: -10°C~+60°C

Working Power: 220VAC(-15%~+10%),50HZ±2%

Weigh Platform Intensity: 1/1000

SCS-120t 3*18m 120t Electronic Lorry Weighbridge Truck Weighing Systems High Accuracy
