Steel Plate Truck Weighing Equipment For Road Overloading Detection Station
Steel Plate Truck Weighing Equipment For Road Overloading Detection Station
Specifications
Brand Name :
PINGLEI
Model Number :
SCS
Certification :
ISO9001
Place of Origin :
SHIJIAZHUANG
MOQ :
1set
Price :
negotiation
Payment Terms :
L/C, T/T
Supply Ability :
15 sets
Delivery Time :
15 days
Packaging Details :
in bulk
material :
steel plate
load cell :
ZEMIC
indicator :
DS3
max load :
100tons
size :
3*18meter
thickness :
12mm
Description

Electronic Weighbridge for Road Overloading Detection Station Truck Weighbridge

Characteristics of trcuk scales:

* Combination type

* Simple platform module

* Suitable for analog and digital load cell

* Heavy duty structure

* High production efficiency

* Able to realize production in batch

* Convenient for container transportation

The composition and feature of SCS Series Truck Scale:

It mainly consists of platform,load cells,weighing indicator,connecting assembly, junction box, spacing devices and signal cable.but can also matching printers, large screen monitors, computers, weighing management software ,stabilized voltage supply and other external equipment.

Technical data:

* Weighing Accuracy:OIML Class III

* Working voltage: ~220V(180V~245V)/50Hz

* Relative humidity: ≤95%RH

* Working temperature:-10°C~50°C(instrumentation).-30~70°C(transducer)

Truck Scale Model Selection Guide (OIML III)

Series

Parameter

 SCS-20 SCS-30 SCS-40 SCS-50 SCS-60 SCS-80 SCS-100
Rated load(t) 20 30 40 50 60 80 100

Division d(kg)

Division e(kg)

5,10

10

5,10

10

10,20

20

10,20

20

20

20

20

20

20,50

20,50
Load cell×number 20t×4 20t×4/6

20t×4/6

25t×4/6

25t×4/6

30t×4/6

25t×4/6

30t×4/6

 30t×4/6

30t×4/6

40t×4/6

Size

(length × width)

Length:7,8,9,10,12,14,16,18,20,22,24 meters, etc..

Width:3,3.2,3.4 meters, etc..

Platform size can be customized!(length≤10m,generally adopt 1 platform/4 load cells;9~12m,adopt two platform,6 load cells. length≥10m
Weighing indicator

FS3198-A2, XK3190-A9 for analog load cells,

XK 3190-DS3, D2008F, for digital load cells etc..

Printer EPSON LQ-300K,Panasonic KX-P1131,optional.
Temperature(°C) -10°C~+40°C
Power Source AC220V±10% /50Hz,or tailored power source.
Computer system(optional parts) above 586 computer,weighing management software under Windows system.

( Note: the electronic truck scale of lightning preventions are an optional work system, they should be completed by user. )
