PCB circuit board (PCB)

also known as printed circuit boards, printed circuit board,

or PCB, English abbreviation PCB (printed circuit board) or the PWB (printed wiring

board), insulation board as base material, cut into a certain size, with at least one

conductive graphics, and cloth have a hole (such as component hole, fastening hole,

hole metallization, etc.), is used to replace previous device electronic components of

the chassis, and realize the connection between the electronic components.Because the

board is made by electronic printing, it is called "printed circuit board".The

customary term "printed circuit board" is not accurate, because there are no "printed

components" on the printed board, only the wiring.
Second, the basic composition
At present, the circuit board is mainly composed of the following:
1. Circuit and Pattern: The circuit is used as a tool to conduct between the original

parts. In the design, a large copper surface will be additionally designed as the

grounding and power layer.The lines and drawings were made at the same time.
2, Dielectric layer (Dielectric) : used to maintain the insulation between the lines

and the layers, also known as the substrate.
3, hole (Through hole/via) : Through hole can make more than two levels of lines

Through each other, the larger Through hole is used as part plug-in, in addition to

the non-through hole (NPTH) is usually used as a surface mount positioning, fixing

screws used during assembly.
4, Solder resistant ink (Solder resistant /Solder Mask) : not all copper surface to

eat tin parts, so non-tin eating area, will print a layer of isolation copper surface

to eat tin material (usually epoxy resin), to avoid short circuit between non-tin

eating tin lines.According to different technology, divided into green oil, red oil,

blue oil.
5. Legend /Marking/Silk screen: This is not necessary. Its main function is to mark

the name and position box of each part on the circuit board, which is convenient for

maintenance and identification after assembly.
6, Surface treatment (Surface Finish) : because the copper Surface in the general

environment, it is easy to oxidize, leading to the tin (poor soldering), so it will be

protected on the copper Surface to eat tin.The protection methods are HASL, ENIG,

Silver, Tin, OSP, each method has its advantages and disadvantages, collectively

referred to as surface treatment.
