ROHS Green Single Sided PCB Board For 500 Watt Amplifier
ROHS Green Single Sided PCB Board For 500 Watt Amplifier
ROHS Green Single Sided PCB Board For 500 Watt Amplifier
ROHS Green Single Sided PCB Board For 500 Watt Amplifier
Specifications
Brand Name :
HF
Model Number :
Single Sided PCB Board
Certification :
ISO CE
Place of Origin :
China
MOQ :
5PCS
Price :
Negotiable
Payment Terms :
L/C, T/T,PAYPAL
Supply Ability :
1000/㎡/day
Packaging Details :
box/carton packing
Delivery Time :
5~8 days
Base Material :
fr-4
Number of Layers :
single layer
Board Thickness :
1.2mm
Copper Thickness :
1oz
Solder mask color :
green
silkscreen color :
white
surface finishing :
osp HASL(lead free)
Min. Hole Size :
0.25mm
service :
One Stop Turnkey service
Material :
FR4 ,Rogers , Aluminum ,High TG,CEM1, CEM3, Halogen Free
Layer Coun :
1-40
Test :
100% AOI, X-ray, Flying probe test.
Description

Company profile

Our main products are PCB customization and OEM , among which PCB customization products are divided into multi-field PCB, HDI PCB, high frequency and high speed PCB, special PCB.OEM products are divided into multi-field PCBA OEM and component OEM.

Our main products are PCB customization and OEM , among which PCB customization products are divided into multi-field PCB, HDI PCB, high frequency and high speed PCB, special PCB.OEM products are divided into multi-field PCBA OEM and component OEM.

Keywords pcba smt assembly
Product Description:
Base Material: FR-4
Board Thickness:0.4～3.2mm
Number of Layers: single Layer
Price: Negotiable
Min. Line Width:3 Mil
Min. Line Spacing:3 Mil
Surface Finishing:HASL(lead Free) / Immersion Gold /osp / Immersion tin/Immersion silver
Copper Thickness:1.0～3.0 Oz
Min. Hole Size: 4 Mil
Solder mask color:Green ,black, white,blue,yellow, red
Character color:white ,black
Place of Origin: Guangdong, China (Mainland)
Supply Ability:1000/㎡/day
fpc PCB 0-10LAYER
Rigid -Flexible PCB 2-18LAYER
Board Thickness Rigid PCB 0.4-6.0MM
fpc PCB 0.05-0.36MM
Rigid -Flexible PCB 0.4-6.0MM
Copper Thickness inner layer 0.5-8.0 OZ
outer layer 0.5-8.0 OZ
Surface Finishing Hasl 0.3-1.0um
Immersion Gold 0.025-0.1um
OSP 0.2-0.6um
Immersion tin 0.8-1.2um
Solder mask color outer layer Green,black,white,blue,yellow,red
Character color outer layer white ,black, yellow
Min. Line Width inner layer 0.05/0.05MM
outer layer 0.05/0.05MM
Min. Line Spacing inner layer 0.05/0.05MM
outer layer 0.05/0.05MM
Drill Hole Max Diling dameter 6.5MM
Min Diling Diameter 0.1mm
MinSlot 0.60MM
Drilig tolerance PTH:+/-0.075mm NPTH:+/-0.05mm
Slot tolerance PTH:+/-0.10mm NPTH:+/-0.05mm
Board Size Rigid PCB 800*2000MM
fpc PCB 200*800MM
Rigid -Flexible PCB 200*500MM
Drill Aspect Ratio Mechanical hole 12.0:1.0
blind hole 1.0:1.0
Solder mask bridge green oil 0.08MM
white,blue,yellow,red 0.1MM
black oil 0.12MM
Bow and Twist Rigid PCB 0.5-0.75%
core thickness Rigid PCB 0.075MM (excluding copper)
Resin plug hole hole size 0.2-0.35mm
Carbon oil thickness 10um(min)
V - cut Rigid PCB 30 45 60 (Tolerance: + / - 5 degrees)
impedance 50-120 ohm Tolerance: + / - 10 %
PP type Commonly used 1080,2116,7628 ,106
