Fiber Tinned Prototype PCB Board Printed Circuit Board 1.6mm Thickness
Fiber Tinned Prototype PCB Board Printed Circuit Board 1.6mm Thickness
Specifications
Brand Name :
ZHONGYI
Place of Origin :
ZHEJIANG
MOQ :
100 pieces
Price :
please contact me
Payment Terms :
T/T, Western Union, paypal
Supply Ability :
please contact me
Delivery Time :
1 day
Packaging Details :
carton
Hole pitch :
2.54mm
Board Thickness :
1.6mm
Surface Finishing :
Tinning
Base Materia :
Fiber tinned
Description

Fiber Tinned Prototype PCB Board Printed Circuit Board 1.6mm Thickness

Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: ZHONGYI
  • Base Material: Fiber tinned
  • Copper Thickness: 0.1mm
  • Board Thickness: 1.6mm
  • Surface Finishing: Tinning
  • Hole pitch: 2.54mm

Packaging & Delivery

Packaging Details: 10 pieces a box

Specifications

Each unit will accept transistors, diodes, LEDS, resistors, capacitors and virtually all types of components.
Our company produ

Each unit will accept transistors, diodes, LEDS, resistors, capacitors and virtually all types of components.

Features:
  • Brand new and high quality.
  • Material: Single Side Copper PCB.
  • Hole Dia: about 1mm.
  • Hole pitch: standard 2.54mm.
  • For point to point DIY soldering.
  • Size:7cm x 9cm - 1.97inch x 2.76inch.
  • Quantity:10.
    Copper Thickness 0.1mm
    Board Thickness 1.6mm
    hole count ....
    size 5*7cm~50*50cm
    material FR-4
    Layer 1-20

produce two layer, four layer, eight layer PCB circuit board and26 layers, and to undertake PCB board independent developmentprogramming. To achieve various functions used in all kinds of household electrical appliances and automotivemanufacturing industry. Also provides revisio serviclife.


Plate thickness 0.30mm-- 6.0mm, plating thickness is 0.007 (alloy)PCB board.Processing types of single, double-sided board, multilayer board,control all kinds of special requirements of the circuit board (such ashigh-frequency board, aluminum board etc.)

Plate thickness 0.30mm-- 6.0mm
plating thickness 0.007 (alloy)PCB board
The plate 0.3mm-- 3.0mm
The maximum size 670mm × 510mm
Minimum pad diameter 20MIL (0.5mm)
smallest metallized hole Huankuan 6mil (0.15mm)
minimum diameter of 12mil (0.3mm) forming
minimum Xian Kuan 8mil (0.2mm)
Minimum line gap 8mil (0.2mm)
older resist liquid photosensitive ink 4mil (0.10mm) 8mil (0.20mm)
Shape processing NC milling error 4mil (0.1mm)
CNC drilling location error of 1mil (0.025mm)
Forming hole maximum aperture error 1mil (0.025mm)
The product warp degree 0.7%

Welcome to our Store
If you buy more quantity, Please contact us
Why directly choose us:

1. All the goods for sale are in stock,we can ship to you within 2 working days.
2. We have many different kinds of goods (all in one shop)
And more important ,you will get the lowest price with high qanlity.
