30 Persons / Min Electronic Turnstile Gates Senor Alarm For Government Reception Hall
30 Persons / Min Electronic Turnstile Gates Senor Alarm For Government Reception Hall
Specifications
Brand Name :
Jiaxuntong
Model Number :
BDS707A
Certification :
CE
Place of Origin :
Made In China
MOQ :
1 set
Supply Ability :
300 per month
Packaging Details :
wooden case
product name :
Electronic turnstile gates
Anti-reverse :
Anti-reverse function in order to ensure one card for one person
housing thickness :
National standard 1.5mm
Application :
In door
Warranty :
1-2 year
Pass speed :
30 persons/min
Description

Government reception hall speed gate with senor alarm swing gate turnstiles for sale

Details :

Power consumption 50W 100W
Housing Size 1600x170x950 mm
Housing material 1.5--2mm, #304 Stainless Steel, Matt finish
Drive motor DC brushless motor
Channel width 600--1100mm
Pass speed 30 persons/min.
Power supply AC220V / 110V (optional)
Input interface Switch Volume or 12V Level
Communication interface RS485
Gate open while power off Yes
Working temperature -30°C~+70°C
Working environments Indoor
Relative humidity ≤95% coagulation free
MCBF 1,500,000 cycles
Warranty 1 year
Outside packing Plywood box, 1650x260x1100 mm

More functions :

  1. Provide normally open / normally close to satisfy management request.
  2. Compatible with RF card readers, bar code readers, biometric readers, push button...
  3. Equipped with infrared photocell, alarm while unauthorized entry or tailgating attempts, together with anti-strike function to protect pedestrian.
  4. Expanded to automatic identification system, access control system, Traffic control, attendance check and fare collection system etc.
  5. Automatically reset : lock automatically while the pedestrian not pass the lane in the pre-set time after the flap opened. The passing time is adjustable.
  6. Equipped with international interface, can be easily integrated with other R/W device and managed through remote supervision computer
  7. (Optional) Support gate open while power failure and recover N/C mode after power on.
  8. (Optional) Memory function. Can pass N pedestrians continuously by swiping card N times correspondingly (N<=16)
  9. (Optional) Reversed passing alarm function, barrier will alarm if pedestrian pass from opposite direction after reading the card.
  10. One direction or bi-direction is optional.
