Digital Display Concrete Testing Machine Manual Control And Hydraulic Loading Mode
Digital Display Concrete Testing Machine Manual Control And Hydraulic Loading Mode
Digital Display Concrete Testing Machine Manual Control And Hydraulic Loading Mode
Digital Display Concrete Testing Machine Manual Control And Hydraulic Loading Mode
Specifications
Brand Name :
wangtebei
Model Number :
YES YAW
Place of Origin :
China
MOQ :
1 set
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
20 sets per month
Delivery Time :
5-8 working days
Packaging Details :
export package
Product name :
Digital display concrete compression testing machine
Diameter of piston :
250mm
Rated pressure of oil pump :
40Mpa
Power :
3 phase 0.75kW
Dimension :
800x500x1200
Weight :
1200kg
Description
Product Description

For determining the compressive and flexural strength of concrete, brick, stone and other

building material. It loads hydraulic pressure and is main specified of building highway and

building industry. The data is automatically output, connect with computer and easy to operate.

Main Features

• Meet the requirements of EN 12390-4 ASTM C39, AASHTO T22
• Tests 200, 150 and 100 mm concrete cubes and cylinders up to 320 x 160 mm diameter
• Load pacing facility fitted as standard
• Platen handling machines include BS 6073-1, EN 772-1 specification rectangular platens.
• Supplied with Windows download software.

Specification

No. Product name Digital display concrete compression testing machine
1 model YES-2000 YES-3000
2 Max. capacity 2000KN 3000KN
3 Force measuring range 4%-100%
4 Relative error of test force ≤±1%
5 Control mode Manual control and hydraulic loading
6 Ball screw adjusting mode Manual Electrical adjusting
7 Size of upper and lower compression plate

Upper: Φ225mm

Lower: Φ300

 370x370mm
8 Max. compression space 320mm 330mm
9 Piston stroke 30mm 50mm
10 Diameter of piston 250 310mm
11 Rated pressure of oil pump 40 40Mpa
12 Power 3 phase 0.75kW 3 phase 1.1kW
13 Dimension 800x500x1200 1000x600x1500mm
14 Weight 1200kg 1800kg

No. Product name Computer control concrete compression testing machine
1 Model YAW-2000 YAW-3000
2 Max. capacity 2000KN 3000KN
3 Force measuring range 2%-100%FS
4 Relative error of test force ≤±1%
5 Ball screw adjusting mode Electrical
6 Size of upper and lower compression plate 370x370mm 400x500mm
7 Max. distance between upper and lower compression plate 330mm 500mm
8 Max. stroke of piston 100mm 150mm
9 Piston diameter 310mm 400mm
10 Rated pressure of oil pump 40Mpa
11 Power 3 phase 1.1kW
12 Dimension 700x700x1600mm 800x800x1800mm
13 Weight 1600kg 2300kg
Packaging & Shipping

We can use the different international express company, usually, our first choice is

DHL. if you have specified requirement , pls inform us before the order.
