Electro Optical Surveillance System UAV EO IR Camera With Ethernet Video Output
Electro Optical Surveillance System UAV EO IR Camera With Ethernet Video Output
Specifications
Brand Name :
HONPHO
Model Number :
TS01CT-N
Certification :
ISO9001:2015/GB/T 19001-2016
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Supply Ability :
30pcs per Month
Packaging Details :
Air packing case
Product name :
EO IR Camera
Dimension :
≤Φ120mm×184mm
Weight :
≤950g
Voltage :
12V
Power consumption :
Average:≤15W, Peak: ≤30W
Working temperature :
-20~60°
Description

Three Axis EO Sensor IR Sensor EO IR Camera With Ethernet Video Output​

TS01CT-N is network three- axis gyro stabilized gimbal airborne EO IR camera for UAV , 360° continuous rotation servo motor, Built-in 30X HD zoom camera and 640x 512 IR module , the total weight about 950g.TS01CT-N airborne EO IR camera with light weight, mature and high stabilization accuracy pan tile servo system technology, and can be asse, it can also be assembled on UAV,ships and vehicles to meet the needs of sea and air.

Functions

1. Provide the visible uncooled LWIR video and image for detection area

2. High precision visual axis stabilization function

3. With the capability of detection and recognition for ground target

4. Support search, tracking, lock, guiding, etc working ways

5. With character overlay, custom and display functions;

6. With self - check and fault diagnosis function

7. UDP control and video (UDP/RTSP) transmission by Ethernet

8. IR Pseudo-color temperature measurement

9. Built in video and image storage

Specifications

EO sensor Wavelength 0.4μm～0.9μm
Resolution 1920x1080
Focal length 4.3mm～129mm(30X)
FOV 63.7°～2.3°
Video output HD-SDI(1080P 30Hz)
Distance PEOPLE:Detection 6km;Recognition 2km VEHICLE:Detection 15km;Recognition 8km
IR sensor IR Type LWIR(un-cooled)
Wavelength 8～14μm
Resolution 640x512
Pixel 12um
NETD 50mk
Focus length 35mm/F1.0
FOV 12.5º×10º
Distance PEOPLE:Detection 1km; Recognition 0.25km
VEHICLE:Detection 6km; Recognition 1.5km
Servo System Rotating limits 360º continuous Pan, Pitch: -110° ~+10 º
Angular accuracy: ≤2mrad
Stablization accuracy ≤100μrad(1σ)(2°/Hz,1°/Hz Swing)
Max.angular speed ≥50°/s
Max. angular acceleration: ≥90°/S
Tracking Functions Motion speed: 30pixel/frame
Target imaging contrast: 8%
Target imaging pixel(Mini) 4x3 pixels
Support Anti -occlusion without loss of function
Interface Communication
interface		 RS422 x2(TTL optional)
Video output 100mb Ethernet

Mechanical Drawing

Electro Optical Surveillance System UAV EO IR Camera With Ethernet Video Output

Company Profile

Chengdu HONPHO Technology Co., Ltd. was established in March 2018. It is a national high-tech enterprise focusing on R&D, intelligent manufacturing and service of high-end photoelectric system. HONPHO main product is spherical photoelectric payload systems, this payload wildly deployed in UAV,unmanned ships, umanned vehicle,helicopter and low speed fixed wing aricrafy. especially for reconnaissance and strike UAV and armed helicopter. HONPHO has nearly 5,000 square meters of space to meet the needs of R&D, production, operation and office. More than 100 employees, include 2 national senior experts, 3 doctors, 21 masters, 10 technical experts with senior titles and 4researchers are joined HONPHO. HONPHO won more than 10 prizes of national and national defense science and technology progress , and have over 20 intellectual property rights. We are committed to building HONPHO into a world-renowned photoelectric system high-tech enterprise

Electro Optical Surveillance System UAV EO IR Camera With Ethernet Video Output

Certificate of HONPHO

Electro Optical Surveillance System UAV EO IR Camera With Ethernet Video Output
