Specifications
Brand Name :
HONPHO
Model Number :
TS130C-01
Certification :
ISO9001:2015/GB/T 19001-2016
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Supply Ability :
30pcs per Month
Packaging Details :
Air packing case
Delivery Time :
1 month
EO sensor Video output :
HD-SDI(1080P 30Hz)
Product Category :
Infrared Thermal Camera
EO sensor FOV :
63.7°~2.3°
IR sensor Wavelength :
8μm~14μm
IR sensor Focal length :
35mm/F1.0
IR sensor hFOV :
12.5°x10°
Max.angular speed :
≥50°/s
Description

Product Description:

The Infrared Thermal Camera is equipped with the capability of detection and recognition for ground targets, and it supports search, tracking, lock, guiding, and other working modes. It also comes with character overlay, custom and display functions, which make it a versatile infrared thermal video system for different applications.

With its self-check and fault diagnosis function, the Infrared Thermal Camera can identify any issues and provide real-time feedback. It supports target position, which makes it easier to locate and track targets in real-time.

Features:

  • Product Name: Infrared Thermal Camera
  • EO sensor Resolution: 1920x1080
  • Features:
    • High-quality infrared thermal video camera
    • Precision infrared thermal detector system
    • Advanced infrared thermal imaging sensor

Technical Parameters:

Technical Parameter Description
Video output Ethernet
Angular accuracy ≤2mrad
IR sensor Focal length 35mm/F1.0
EO sensor Wavelength 0.4μm~0.9μm
EO sensor Video output HD-SDI(1080P 30Hz)
IR sensor hFOV 12.5° x 10°
Rotating limits 360º continuous Pan, Pitch: -110° ~+10 º
IR sensor Wavelength 8μm~14μm
Stablization accuracy ≤100μrad(1σ)(2°/Hz,1°/Hz Swing)
Dimension ≤Φ130mm×181mm

Applications:

The HONPHO TS130C-01 Infrared Thermal Camera is ideal for a wide range of applications, including but not limited to:

  • Building inspections: Infrared thermal imaging cameras can be used to identify areas of heat loss in buildings, which may indicate problems with insulation, air leaks, or other issues. The HONPHO TS130C-01 Infrared Thermal Camera can help building inspectors to identify these issues quickly and accurately.
  • Firefighting: Infrared thermal imaging cameras can help firefighters to locate people or animals in a burning building or to identify hot spots that may indicate areas of the fire that require attention. The HONPHO TS130C-01 Infrared Thermal Camera is an essential tool for firefighters and rescue workers.
  • Wildlife observation: Infrared thermal imaging cameras can be used by wildlife researchers to observe animals at night without disturbing them. The HONPHO TS130C-01 Infrared Thermal Camera can help researchers to identify and study nocturnal animals.

The HONPHO TS130C-01 Infrared Thermal Camera is a powerful tool that can be used in a wide range of scenarios. It is an infrared thermal video camera that can be used to capture high-quality images and video in low-light and no-light environments.

Support and Services:

Our Infrared Thermal Camera product comes with a comprehensive technical support and services package to ensure that our customers receive the best possible experience. Our team of experts is available to assist with any technical queries or issues that may arise and can provide guidance on how to best utilize the features of the camera. We also offer regular software updates to ensure that our customers always have access to the latest features and functionality. In addition, we provide training and education services to help users get the most out of their camera, including on-site training at the customer's location. Finally, we offer extended warranty and repair services to provide peace of mind and ensure that our customers can continue to use their camera for years to come.

Packing and Shipping:

Product Packaging:

Our Infrared Thermal Camera is carefully packaged to ensure its safety during transportation. It is packed in a sturdy cardboard box with foam inserts to prevent any damage during shipping. The box is labeled with the product name, description, and handling instructions.

Shipping:

We offer free and fast shipping for our Infrared Thermal Camera to customers worldwide. We use reliable shipping carriers and provide tracking information to ensure that our customers can monitor their delivery. We also offer expedited shipping options for customers who require their orders to arrive sooner.

FAQ:

Q: What is the brand of this infrared thermal camera?

A: The brand of this infrared thermal camera is HONPHO.

Q: What is the model number of this infrared thermal camera?

A: The model number of this infrared thermal camera is TS-01GD.

Q: Does this infrared thermal camera have any certification?

A: Yes, this infrared thermal camera is certified with ISO9001:2015/GB/T 19001-2016.

Q: Where is this infrared thermal camera made?

A: This infrared thermal camera is made in China.

Q: What is the minimum order quantity for this infrared thermal camera?

A: The minimum order quantity for this infrared thermal camera is 1.

Q: Is the price of this infrared thermal camera negotiable?

A: Yes, the price of this infrared thermal camera is negotiable.

Q: What is the supply ability of this infrared thermal camera?

A: The supply ability of this infrared thermal camera is 30pcs per month.

Q: How is this infrared thermal camera packaged during shipment?

A: This infrared thermal camera is packaged in an air packing case.

Q: What is the delivery time for this infrared thermal camera?

A: The delivery time for this infrared thermal camera is 1 month.
