Quality Sliding Door Operator Products China Automatic Sliding Door for Sale
Quality Sliding Door Operator Products China Automatic Sliding Door for Sale
Quality Sliding Door Operator Products China Automatic Sliding Door for Sale
Quality Sliding Door Operator Products China Automatic Sliding Door for Sale
Specifications
Brand Name :
Elegint
Model Number :
DE125B
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
USD200-380/set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3000 sets/month
Delivery Time :
3 working days
Packaging Details :
Plastic Coat + Shaped foam box + Inner Carton + Outer carton
Material :
Aluminum Profile
Track Length :
4.15m for dual open/ Customized
Motor :
24V Brushless DC Motor
Name :
China Automatic Sliding Door
Description

Functional Characteristics

Intelligence-Configured with built-in intelligent micro-computer control chip to achieve automatic process. It precisely proceed opening and closing speed, holding time once these parameters have been set by the users;

Reliability-Internationally used brushless DC motor integrated with worm gear reducer possesses high efficiency, long life span, reliable and low noise characteristics.

Safety-Selective safe sensor devices completely eliminate the clamping danger. The program won’t disorder even if someone pulls/pushes the door leaves. The door leaves will move reversely if there is any object approaching the door during its closing procedure.

Outstanding Access Control Devices-Remote control adapter realizes open, half open, lock and automatic operation options easily. And can match other optional access controllers to realize access control, networking checking attendance, security monitoring and other all-dimensional intelligent functions.

Noise Insulation Design-Upgraded design of transmission modules form a precise structure matched with polyurethane covered pulleys which enable the door moves more brisk, and reduce the noise at the same time;

Energy Saving-Open sensitive, closed timely, minimize the air circulation between the internal air-conditioning environment and outdoor environment, maintain constant temperature indoors.

Environmental Protection-Double-door interlock structure can reduce indoor cleansing air spillover out, prevent cross contamination, meet energy saving requirements and noise insulation needs.

Technical Specification

Parameter DE-125B
Range of the Door Single-leaf Double-leaf
Door Leaf max Weight 150kg 150kg x 2
Door Width 650-1400mm 650-1250mm
Installation Type Surface Mounting
Max Door Leaf Thickness 50mm
Motor DC24V, 60W
Power Supply AC220±10%, 50-60 Hz
Input Current (Standby) 0.095A
Input Current(Operation) 1.6A
Opening Speed 150-750mm/s (adjustable)
Closing Speed 150-750mm/s (adjustable)
Creep Speed 30-100mm/s (adjustable)
Hold-open Time 2-20s (adjustable)
Hold-Close Force 70N<f<220N
Manual Pushing Force <120N
Power Consumption <150W
Ambient Temperature -20+50 ℃

Quality Sliding Door Operator Products China Automatic Sliding Door for Sale

Packed Aluminum Track:

Quality Sliding Door Operator Products China Automatic Sliding Door for Sale

Components Packing:

Quality Sliding Door Operator Products China Automatic Sliding Door for Sale
