China Factory Supplied Automatic Sliding Door Kit with Competitive Price
China Factory Supplied Automatic Sliding Door Kit with Competitive Price
Specifications
Brand Name :
Elegint
Model Number :
120A
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
USD200-380/set
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
3000 sets/month
Delivery Time :
5 working days
Packaging Details :
Plastic coating each component and then put into shaped foam box and then packed into inner and outer cartons
Material :
Aluminium Profile
Position :
Exterior/ Commercial
Track Length :
4.15 m or Customized
Name :
Glass Sliding Door System
Description

Elegint Automatic Sliding doors are adaptable to different installation requirements. It’s designed for heavy traffic situations both for heavy pedestrian volume places(Supper markets,airtports,hospitals,etc) and small and medium-sized users (offices,chemists,restaurants,etc).

Characteristics and Advantages

(1) Safety: Operated by receiving signals from sensors, the door moves automatically and it will reverse back once there is any objects between the door leaves and with safety sensor installed at both sides to enhance the safety;

(2)Easy to Install: Modularization design makes installation quite easy, just need to fix each part into the track and connect the wires, it will run accordingly;

(3)Reliability: Adopt with small brushless DC motor and low noisy high speed gear box and input with safety device, which enables it can be open and close frequently in a long term. And the belt wheel on the motor is made of metal which avoids emendation after installation;

(4)Wide-Adaptability: It can be used both for framed door bodies or frameless glass doors; are available in either single sliding, bi-parting or telescopic configurations;

Technical Specification

Parameter DE-120A
Range of the Door Single-leaf Double-leaf
Door Leaf max Weight 180kg 130kg x 2
Door Width 650-1400mm 650-1250mm
Installation Type Surface Mounting
Max Door Leaf Thickness 50mm
Motor DC24V, 60W
Power Supply AC220±10%, 50-60 Hz
Input Current (Standby) 0.095A
Input Current(Operation) 1.6A
Opening Speed 150-750mm/s (adjustable)
Closing Speed 150-750mm/s (adjustable)
Creep Speed 30-100mm/s (adjustable)
Hold-open Time 2-20s (adjustable)
Hold-Close Force 70N<f<220N
Manual Pushing Force <120N
Power Consumption <150W
Ambient Temperature -20+50 ℃

Picture of Driving System

China Factory Supplied Automatic Sliding Door Kit with Competitive Price
