Dia 100mm Small Household Elevator Traction Machine Lift Gearless Motor Traction Machine
Dia 100mm Small Household Elevator Traction Machine Lift Gearless Motor Traction Machine
Dia 100mm Small Household Elevator Traction Machine Lift Gearless Motor Traction Machine
Dia 100mm Small Household Elevator Traction Machine Lift Gearless Motor Traction Machine
Dia 100mm Small Household Elevator Traction Machine Lift Gearless Motor Traction Machine
Dia 100mm Small Household Elevator Traction Machine Lift Gearless Motor Traction Machine
Dia 100mm Small Household Elevator Traction Machine Lift Gearless Motor Traction Machine
Dia 100mm Small Household Elevator Traction Machine Lift Gearless Motor Traction Machine
Specifications
Brand Name :
ZANFENG
Model Number :
ZFG100 100mm
Certification :
ISO9001
Place of Origin :
Shanghai
MOQ :
1 Piece
Price :
Negotiable,USD1200-USD2000
Payment Terms :
L/C, T/T
Supply Ability :
1000 Piece/Pieces per Month
Delivery Time :
5~10 work days
Packaging Details :
Standard Export Packing, Fumigation-free wooden cases.
Voltage :
220V-380(V)
Roping :
2:1
Wrap :
Single
Elv.Load :
320-630(kg)
Elv.Speed :
0.4m/s 0.5m/s 0.63m/s 1m/s
Sheave Diam :
100mm
Duty :
S5-40%
Max. Static Load :
2500kg
Weight :
140kg
Brake :
DC110V 1.8
IP Code :
IP41
Ins. Class :
F
Description

ZFG100 S Dia 100mm Small Household Elevator Accessories Traction Machine Lift Tractor Gearless Motor Traction Machine

Gearless Motor Traction Machine

Gear-free elevator traction machine is a special type of traction machine, which is used to drive the elevator operation of gear-free drive system. Compared with the traditional gear drive, the gear-free traction machine has some unique characteristics and advantages.

The characteristics of gear-free elevator traction machine are as follows:

1,Gear-free design: traditional elevator traction machines usually use gears to transmit power. The gear-free elevator traction machine adopts a gear-free design, which transmits power and pushes the elevator up and down through high-strength steel belts or wire ropes and special traction wheels.

2,Stability and mute: because the gear-free elevator traction machine does not have the friction and noise of traditional gears, the operation of the elevator is more stable and mute. Taking a gear-free elevator can provide a more comfortable ride experience.

ZFN200 ZFN200A MODEL RECOMMENDED FOR

Specification Ratio Load(Kg) Speed(m/s) Motor Sheave
Voltage(V) Power(KW) Current(A) Frequency(Hz) Pole(P) Speed(r/min) Torque(N*m) Energy(%) S Dia. (mm) R No. R Dia. (mm) R Dist (mm) Groove β° γ° RLH(m)
ZFG100-320-040A1 2:1 320 0.4 220 1 7 20.4 16 153 60 69.9 100 60+5+60+5+60+5+60+5+60 2 60 20
ZFG100-400-040A1 400 1.2 8 75 71.1 20
ZFG100-320-050A1 2:1 320 0.5 220 1.2 7 25.5 16 191 60 71.8 100 60+5+60+5+60+5+60+5+60 2 60 25
ZFG100-400-050A1 400 1.6 8 75 73.9 25
ZFG100-450-050A1 450 1.6 8 80 73.9 25
ZFG100-630-050A1 630 2.2 12 110 75.9 3 60 25
ZFG100-320-063A1 2:1 320 0.63 220 1.5 7 32.1 16 241 60 73.6 100 60+5+60+5+60+5+60+5+60 2 60 30
ZFG100-400-063A1 400 2 8 75 75.2 30
ZFG100-450-063A1 450 2 8 80 75.2 30
ZFG100-630-063A1 630 2.8 12 110 76.5 3 60 30
ZFG100-320-100A1 2:1 320 1 380 2.4 9 50.9 16 382 60 76.8 100 60+5+60+5+60+5+60+5+60 2 60 40
ZFG100-400-100A1 400 3 12 75 77.3 40
ZFG100-450-100A1 450 3 12 80 77.3 40
ZFG100-320-040A2 2:1 320 0.4 380 1 4 20.4 16 153 60 69.9 100 60+5+60+5+60+5+60+5+60 2 60 20
ZFG100-400-040A2 400 1.2 5 75 71.1 20
ZFG100-320-050A2 2:1 320 0.5 380 1.2 4 25.5 16 191 60 71.8 100 60+5+60+5+60+5+60+5+60 2 60 25
ZFG100-400-050A2 400 1.5 5 75 73.6 25
ZFG100-450-050A2 450 1.6 5 80 73.8 25
ZFG100-630-050A2 630 2.2 7 110 75.9 3 60 25
ZFG100-320-063A2 2:1 320 0.63 380 1.5 4 32.1 16 241 60 73.6 100 60+5+60+5+60+5+60+5+60 2 60 30
ZFG100-400-063A2 400 1.9 5 75 74.9 30
ZFG100-450-063A2 450 2 5 80 74.7 30
ZFG100-630-063A2 630 2.8 7 110 76.5 3 60 30
ZFG100-320-100A2 2:1 320 1 380 2.4 6 50.9 16 382 60 76.8 100 60+5+60+5+60+5+60+5+60 2 60 40
ZFG100-400-100A2 400 3 8 75 77.3 40
ZFG100-450-100A2 450 3 8 80 77.3 40

Optional Table

Type Load(Kg) Speed(m/s) Sheave(mm) Voltage(V)
Outer rotor traction machine
ZFW320 320-630 0.5-1.75 320 380
ZFW400L 630-1050 0.5-2.5 400 380
ZFW400L 630-825 0.5-2.5 450 380
ZFW400L 1000-1150 0.5-2.5 400/450 380
ZFW400L 1250-1600 0.5-2.5 400/480 380
ZFW480 1250-1600 1.0-2.5 450/550 380
ZFW480 2000-2500 0.5-3.0 450/480 380
Inner rotor traction machine
ZFN320 630-1150 0.5-1.75 320 380
ZFN450 1600-3000 0.5-3.0 450 380
ZFN450 1600-3000 0.5-3.0 480 380
ZFN450 1600-3000 0.5-3.0 520 380
Household elevator traction machine
ZFN200 320-450 0.4-1.0 200/240 220/380
ZFN200A 320-450 0.4-1.0 200/240 220/380
ZFG100 320-630 0.4-1.0 100 220/380
ZFG87 320-450 0.4-1.0 87 220/380
ZFG87 320-450 0.3-0.5 65 220/380
