Chrome Plated Carbon Steel Round Bar High Performance Forging Grinding Rod Dia 20mm - 90 Mm
Chrome Plated Carbon Steel Round Bar High Performance Forging Grinding Rod Dia 20mm - 90 Mm
Chrome Plated Carbon Steel Round Bar High Performance Forging Grinding Rod Dia 20mm - 90 Mm
Chrome Plated Carbon Steel Round Bar High Performance Forging Grinding Rod Dia 20mm - 90 Mm
Chrome Plated Carbon Steel Round Bar High Performance Forging Grinding Rod Dia 20mm - 90 Mm
Chrome Plated Carbon Steel Round Bar High Performance Forging Grinding Rod Dia 20mm - 90 Mm
Chrome Plated Carbon Steel Round Bar High Performance Forging Grinding Rod Dia 20mm - 90 Mm
Chrome Plated Carbon Steel Round Bar High Performance Forging Grinding Rod Dia 20mm - 90 Mm
Specifications
Brand Name :
elite-indus
Model Number :
Elt-Rod
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1Pieces
Price :
Negotiation
Payment Terms :
L/C, D/P, T/T, Western Union
Supply Ability :
6000pcs per month
Delivery Time :
5-8 working days
Packaging Details :
Wood Box
rod Length :
100mm-12000mm
surface roughness :
Ra0.4-0.1 (∆8-∆10)
Materials :
42CrMo and 40Cr, 45# Steel
Product name :
B2 steel round bar High Performance Forging Grinding Rod Dia 20mm - 90 mm
Rod Surface Treatment: :
Hard chrome plated, Chrome/Nickel plated, Ceramic coated
Coated :
chrome plated
Type :
round solid bar hollow bar
Description

B2 chrome plated carbon steel round bar High Performance Forging Grinding Rod Dia 20mm - 90 mm

Features chrome plated carbon Steel Round Bar :

Backed by the rich experience and a competent team of professionals, we are able to offer Hard Chrome Plated Rods.

The offered range of hard chrome plated rods is made utilizing highly modern machines and sophisticated technology at reliable vendors' premises.

Along with this, the offered range of hard chrome plated rods is appreciated in the market for its sturdiness and durability.

Lightweight Defect-free Completely tested

Chrome Plated Carbon Steel Round Bar High Performance Forging Grinding Rod Dia 20mm - 90 Mm

Specification of chrome plated carbon Steel Round Bar

Item Elt-Roll 1 Elt-Roll 2 Elt-Roll 3

Length

 100-3000mm 500-6000 1000-12000

surface roughness

 Ra0.4-0.1(∆8-∆10)

surface hardness 

 HRC60 straightness 0.15/1000mm
Turning Roundness <=0.01/overall length chromeplate thickness 0.015
Total Length Error <=0.02 Materials 45# steel

Basic parameters chrome plated carbon Steel Round Bar:

Comparison of Mechanical Properties of 42CrMo and 40 Cr, 45# Steel

Material

Heat Temperature oC
Quenching Tempering

g

N/mm2

(kgf/mm2)

S

N/mm2

(kgf/mm2)

5

%

 %

AK(ak)

(kgf.m/cm2)

Temperature

Medium

Temperature

Medium

Not less than
45 840 600 600(61) 355(36) 14 40 31(4)
40Cr 850 Oil 520 Water Oil 980(100) 785(80) 9 45 47(6)
42CrMo 850 Oil 560 Water Oil 1080(110) 930(95) 12 45 63(8)

Chrome Plated Carbon Steel Round Bar High Performance Forging Grinding Rod Dia 20mm - 90 Mm

Features:

Lightweight

Defect-free

Completely tested

Advantages chrome plated carbon Steel Round Bar :

Lighter weights with higher strengths and lower costs

Continuously threaded for maximum versatility or headed on ends only

Threads and components capable of developing the full capacity of the bar

Superior Quality

Backed by the rich experience and a competent team of professionals, we are able to offer Hard Chrome Plated Rods.

The offered range of hard chrome plated rods is made utilizing highly modern machines and sophisticated technology at reliable vendors' premises.

Along with this, the offered range of hard chrome plated rods is appreciated in the market for its sturdiness and durability.

Our range of hard chrome plated rods is fabricated using premium quality raw material making them sturdy and durable.

Further, our range is manufactured using qualitative raw materials which ensures optimum performance at client's end.

Chrome Plated Carbon Steel Round Bar High Performance Forging Grinding Rod Dia 20mm - 90 Mm

Why choose us:

1: Various style for completely series pneumatic products for you to choose

2: High quality with competitive price,100% tested before shipment
3: Sample order & small quantity order is accepted
4: Large stock & fast shipment

5: Factory location near by shipment port,convenient transportation and low cost
