Sunlight Readable Industrial Android Tablet High Precision Multi Point Pcap Touch
Sunlight Readable Industrial Android Tablet High Precision Multi Point Pcap Touch
Sunlight Readable Industrial Android Tablet High Precision Multi Point Pcap Touch
Sunlight Readable Industrial Android Tablet High Precision Multi Point Pcap Touch
Sunlight Readable Industrial Android Tablet High Precision Multi Point Pcap Touch
Sunlight Readable Industrial Android Tablet High Precision Multi Point Pcap Touch
Sunlight Readable Industrial Android Tablet High Precision Multi Point Pcap Touch
Sunlight Readable Industrial Android Tablet High Precision Multi Point Pcap Touch
Specifications
Brand Name :
Shinho
Model Number :
SC15 A
Certification :
CE FCC RoHS
Place of Origin :
Shenzhen,China
MOQ :
1 pcs
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union,Paypal
Product name :
15'' 1000 nits Android Industrial Panel PC
CPU :
RK3288 Cortex-A17 quad core,1.8GHz
Memory :
2G , ( Max. 4G)
Storage :
eMMC 8G , ( Max. 16G)
Resolution :
1024*768
Brightness :
1000 nits,sunlight readable
4G :
Can be produced Built in Huawei 4G module
Wifi Bluetooth :
Build in
Operation System :
Android 5.1
IP grade :
Front IP65 waterproof,dustproof
Description

15'' Front IP65 1000 Nits Sunlight Readable Industrial Android Tablet With 2 RS232

Features

1. RK3288 Cortex-A17 quad core,1.8GHz,2G memory, 8G storage.


2. 15'' LCD panel, 1024*768 resolution ,wide viewing angle, high nits, true color.

3. Flat screen with IP65 bezel protection.back case is also with dustproof.

4. 1000 nits,sunlight readable. suitable for outdoor application.


5. Adopt multi point pcap touch, high precision, durable, anti-interference.


6. High performance motherboard, 7x24 continuous operation.


7. With wifi,bluetooth. (3G/4G can be produced.)

8. Android version: Android 5.1 .

15 Inch Android Industrial Panel PC Application

self service machine

marine navigation

advertising player

Vending machines

hotel check-in kiosk

fitness training systems

Self ordering machine

Express delivery locker

Self-service weight machine

Customized module build in

RFID

NFC

3G/4G

Fingerprint Reader

Microphone

Camera

label printer

GPS

Specification

Model:SC15A
PC
CPU RK3288 Cortex-A17 quad core,1.8GHz
Memory 2G , ( Max. 4G)
Storage eMMC 8G , ( Max. 16G)
Decoding Resolution Support maximum 2048*1536
Operation System Android 5.1
Play Modes Support timing, loop and spots etc. play modes
Network Support RJ45, WIFI, 3G, 4G , TD-LTE (optional)
Image Format JPG/BMP/GIF/TIFF/PNG
Video Format RMVB,FLV,MPEG1/2/4, AVI, WMV, MOV, MP4, TS etc.
Audio Format MP3,WMA,AAC,etc.
RTC Real Time Clock YES
I/O Interfaces
USB 2×USB ( up to 5 )
COM 2×COM
LAN 1×RJ45, 10M/100M adaptive ethernet
HDMI 1×HDMI , support 1080p
DC 1×DC
Card Slot 1×TF
LCD panel
Panel size 15"
Resolution 1024*768
Aspect ratio 4:3
Support Color 16.7M colors
Brightness 1000 cd/m² ,sunlight readable
Response time 5ms
Contrast ratio 1000:1
View angle 80°/80°/80°/80° (R/L/U/D)
Touch panel
Touchscreen Type 10 point capacitive touch
Touch response time <2ms
Luminousness 90%
Surface Hardness 7H
Working Life >50 million times
Power Supply
External Power Supply AC 100 - 240V
Working voltage DC 12V
Power consumption ≤45W
Enclosure
Appearance Flat panel
Material Aluminum alloy
Color Black, white, Silver , color can be customized
VESA mounting 75×75mm/100×100mm
IP grade front IP65
Operating Environment
Working temperature -10°C to 55°C
Relative humidity <85%
Vibration resistance 5-19Hz/1.0mm amplitude , 19-200Hz/1.0g acceleration
Impact resistance 10g acceleration , 11ms period
Packing Details
Net weight 5 kg
Gross weight 5.5 kg
Product Dimension 38×30×5.97 cm
Packing size 47×44×18 cm
Accessories Power adapter,embedded screws,warranty card, user manual
Other
Mounting (options) 1) provide wall brackets for wall-mounting, VESA 100×100mm
2) provide stable metal holder to support the monitor
Customization 3G,4G,Webcam, RFID reader etc. optioanal
Warranty 1 year warranty
