10000mAh 700nits Industrial Rugged Android Tablet Gps NFC RFID Reader
10000mAh 700nits Industrial Rugged Android Tablet Gps NFC RFID Reader
10000mAh 700nits Industrial Rugged Android Tablet Gps NFC RFID Reader
10000mAh 700nits Industrial Rugged Android Tablet Gps NFC RFID Reader
10000mAh 700nits Industrial Rugged Android Tablet Gps NFC RFID Reader
10000mAh 700nits Industrial Rugged Android Tablet Gps NFC RFID Reader
Specifications
Brand Name :
Sihovision
Model Number :
R-Q16BM
Certification :
CE, FCC, RoHS
Place of Origin :
CN
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
T/T, Western Union, Paypal, MoneyGram
CPU :
Qualcomm MSM 8953
RAM :
4GB
Storage :
64G SSD
Operation System :
Android 9.0
4G :
Support
GPS :
Support
Camera :
Front:5.0MP, Rear: 13MP
WIFI :
Support
Screen :
10.1"
Resolution :
800*1280 IPS
Brightness :
Minimum 400cd/m2
Touchscreen :
Capacitive(10 points)
Baterry :
3.7V/10000mAh
IP grade :
IP65 waterproof
Description

Specification

Model:R-Q16BM
PC
CPU MSM 8953, 2.0GHZ
GPU Adreno 506 1920 × 1200 @ 60 fps
RAM 4GB/ LPDDR3
SSD 64GB
Indicator light Indicator light of charge, red light will flash when device has low power. red long light when charging, green long light when full power
L-Sensor 1*light Sensor
Compass 1*Compass Sensor
Gyro Sensor 1*Gyro Sensor
G_sensor G_sensor
WIFI WIFI 802.11(a/b/g/n/ac) dual frequency 2.4G+5.8G WIFI intel 3165D2WG (3.3v)
Bluetooth BT4.2 (BLE) class 1, Transmission distance: 10m
2/3/4G CMCC 4M: LTE B1,B3,B5,B7,B8,B20,B38,B39,B40,B41; WCDMA 1/2/5/8; GSM 2/3/5/8
GPS Support: GPS+Glonass; Capture sensitivity: -140 dBm; Cool Start Time: <50s, Hot start time: <5s, GPS frequency: 1575.42MHz,Glonass frequency: 1602MHZ
NFC NFC 13.56MHz support SO/IEC 14443A/14443B/15693/18092/mifare protocol, Card reading distance: 3cm~5cm
Camera Front:5.0MP, Rear: 13MP auto-facus with flashlight
Speaker 8Ω/0.8W waterproof BOX speaker*1
Mic Sensitivity:-42db, output impedance 2.2kΩ
Operation System Android 9.0
LCD panel
Panel size 10.1"
Resolution 800*1280 IPS
Aspect ratio 16:10
Brightness (cd/m²) Minimum 400cd/m2
Touch panel
Touchscreen Type Multipoints Capacitive, G+G
Surface Hardness 7H
Interface
USB 1*USB 3.0
Type C 1*USB OTG/chargeing
Audio Output 1*3.5mm
HDMI 1*HDMI 1.4a Type C
TF Slot 1*TF Slot, support SDHC/SDXC*1 max: 64G
SIM 1*SIM
Power 1*DC 5V 3A
Pogo Pin 1*12pin Pogo Pin
DB9 PORT 1*(RS232) TTL Electrical Level
RJ45 PORT 1*(10/100 Self-adaption)
OTG cable type-c OTG cable
Type-C cable type-c cable
Power Supply
Power Adaptor AC100V ~ 240V, 50Hz/60Hz, Output DC 5.5V/4A
Battery build in polymer li-ion battery
Capacity: 3.7V/10000mAh
nearly 12 hours(50% volume sounds,50% brightness,1080P HD video display by default)
Operating Environment
IP grade IP65 waterproof
Drop Height 1.22cm composite wood floors, in operation status
Operate Temperature -20 °C to 60 °C
Store Temperature -30 °C to 70 °C
Humidity Humidity: 95% Non-Condensing
Packing Details
Net weight 1125g
Gross weight 1913g
Product Dimension 280*187*22mm
Packing size 384*222*64mm
Other
Warranty 1 year warranty
Certificate CE, FCC, RoHS
Color black
Module extension (Optional)
One-dimension barcode MOTO SE655E100R, optical resolution: 5mil, SCAN Speed: 50 times/s, support code system :UPC/EAN, Bookland EAN ,UCC Coupon Code,ISSN EAN,Code 128,GS1-128,ISBT 128,Code 39,Trioptic Code 39 ,Code 32,Code 93 ,Code 11
Two-dimension barcode Honeywell N3680 TTL decoder, optical resolution:5mil, scan speed:50times/s, support code system:PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse, Maxicode,QR Code, MicroQR, QR Inverse,Aztec,Aztec Inverses,Han Xin,Han Xin Inverse
Fingerprint 070-Hello fingerprint module, FPC1020(sensor,capacity press type)
fingerprint effective area: 10mm x10mm  more high resolution: 192x192pixel/508DPI
NFC NFC-ST21
Serial 1*RS232
Ethernet interface 1*(10/100M self-adaption) with indicator light
UHF-RFID UFH, Working spectrum range 902Mhz-928Mhz, inventory tag peak velocity > 50 pcs /second
ID Module support reading the fingerprint information in the 1st and 2nd ID card
Port: USB or TTL serial port optional
power 5v or 3.3v, size: 53mm*52mm*10mm
Optional Accessories
Accessories Docking Charger, Hand-strap, Vehicle Mount, Removable Battery, 5V3A Car Charge, Carry handle, Shoulder-strap, Back-strap

10000mAh 700nits Industrial Rugged Android Tablet Gps NFC RFID Reader
