Open Frame Mounting Portable Touch Screen Monitor With Flat Panel IP65
Open Frame Mounting Portable Touch Screen Monitor With Flat Panel IP65
Open Frame Mounting Portable Touch Screen Monitor With Flat Panel IP65
Open Frame Mounting Portable Touch Screen Monitor With Flat Panel IP65
Open Frame Mounting Portable Touch Screen Monitor With Flat Panel IP65
Open Frame Mounting Portable Touch Screen Monitor With Flat Panel IP65
Open Frame Mounting Portable Touch Screen Monitor With Flat Panel IP65
Open Frame Mounting Portable Touch Screen Monitor With Flat Panel IP65
Specifications
Brand Name :
SHINHO
Model Number :
SL101
Certification :
CE,FCC, RoHS
Place of Origin :
Shenzhen,China
MOQ :
1 Piece
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union,Paypal, MoneyGram
Product name :
Open Frame Capacitive Touch Monitor 10 Inch
Resolution :
1280*800
Aspect ratio :
16:10
View angle :
80°/80°/80°/80° (R/L/U/D)
Product Dimension :
26.8×18.49×3cm
Touch Type :
Project Capacitive Touch (10 points )
IP grade :
Front Panel IP65
Mounting :
Open frame
Description

Open Frame Capacitive Touch Monitor 10 Inch with Flat Panel and 1000 Nit

Sunlight Readable LCD monitors are the best choice for applications where the sun's rays will be falling directly onto the face of the monitor, it;s specifically designed as a low-cost solution for use in bright sunlight
conditions. The 1000 nits brightness enable the user to see sharp, brilliant color video images even in bright ambient (indirect and reflected) light conditions.

Features

1. 10.1 inch TFT LED backlight LCD.

2. Flat panel and front panel IP65 waterproof and dustproof.

3. Supports panel mount, wall mount, rack mount and VESA arm.

4. 10 points capacitive touch.

5. Brightness is 1000 nits.

6. HDMI, DVI-D and VGA signal inputs.

Application

Self-service ordering machine in outdoor

Human Machine Interface

Outdoor Kiosk

Semi-outdoor usage

CNC machinery control

Numerical control device

Other outdoor application

Registered machine

Self-service payment machine



Specifications

Model:SL101
LCD panel
Panel size 10.1"
Resolution 1280*800
Aspect ratio 16:10
Support Color 16.7M colors
Brightness (cd/m²) 1000nits
Contrast ratio 1000:1
View angle 80°/80°/80°/80° (R/L/U/D)
Touch panel
Touchscreen Type Project Capacitive Touch (10 points )
Surface Hardness 3H
Luminousness 90%
Touch Interface USB (RS232 optional)
Touch response time 2ms
Working Life >50 million times
Touch options (4 or 5 wires restive touch, IR touch optional)
Signal Ports
VGA 1×VGA
DVI 1×DVI
HDMI 1×HDMI
Audio in/out optional
OSD
OSD control Brightness, contrast ratio, auto adjustment, H/V position, language select etc.
Support languages English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese etc.
Support OS Windows XP , Windows /7/8/10 , Linux, Mac OS X, Android ect.
Power Supply
External Power Supply AC 100 - 240V , 50-60Hz
Working voltage DC 12V
Power consumption ≤35W
Enclosure
Material aluminium alloy bezel+High strength cold rolled steel back case
Color Black, white, Silver , color can be customized
VESA mounting 75×75mm/100×100mm
IP grade Front panel IP65 waterproof
Operating Environment
Temperature Range operating: -10 to 60°C, storage :-20 to 80°C
Relative humidity operating: 10% to 80% , storage :5% to 90%
Packing Details
Net weight 1.7kg
Gross weight 2.8kg
Product Dimension 26.8×18.49×3cm
Packing size 33×30×10cm
Accessories Power adapter, USB touch cable,HDMI cable, open frame kits
Other
Mounting open frame
wall mounting brackets (optional)
desk stand holder (optional)
Warranty 3 years warranty
Certificates CE, FCC, RoHS

Attention of warranty

1. First year warranty: by free

2. 2nd to 3rd year warranty: maintaining by some charges.

Pictures

Open Frame Mounting Portable Touch Screen Monitor With Flat Panel IP65

Open Frame Mounting Portable Touch Screen Monitor With Flat Panel IP65

Drawing

Open Frame Mounting Portable Touch Screen Monitor With Flat Panel IP65
