7 Inch 1000 Nits Capacitive Touch Monitor 1024*600 Resolution RS232 For Touch
7 Inch 1000 Nits Capacitive Touch Monitor 1024*600 Resolution RS232 For Touch
7 Inch 1000 Nits Capacitive Touch Monitor 1024*600 Resolution RS232 For Touch
7 Inch 1000 Nits Capacitive Touch Monitor 1024*600 Resolution RS232 For Touch
7 Inch 1000 Nits Capacitive Touch Monitor 1024*600 Resolution RS232 For Touch
7 Inch 1000 Nits Capacitive Touch Monitor 1024*600 Resolution RS232 For Touch
7 Inch 1000 Nits Capacitive Touch Monitor 1024*600 Resolution RS232 For Touch
7 Inch 1000 Nits Capacitive Touch Monitor 1024*600 Resolution RS232 For Touch
7 Inch 1000 Nits Capacitive Touch Monitor 1024*600 Resolution RS232 For Touch
7 Inch 1000 Nits Capacitive Touch Monitor 1024*600 Resolution RS232 For Touch
7 Inch 1000 Nits Capacitive Touch Monitor 1024*600 Resolution RS232 For Touch
7 Inch 1000 Nits Capacitive Touch Monitor 1024*600 Resolution RS232 For Touch
Specifications
Brand Name :
Sihovision
Model Number :
SL07
Certification :
CE,FCC, RoHS
Place of Origin :
Shenzhen,China
MOQ :
1 Piece
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, Paypal, MoneyGram
Product name :
7 inch RS232 Touch Screen Monitor
Products status :
Stock
Resolution :
1024*600
Screen size :
7"
Interface :
VGA, HDMI
Brightness :
1000+ nits
IP Grade :
Front panel IP65 waterproof
Viewing angle :
75°/75°/70°/75° (R/L/U/D)
Touchscreen Type :
Project Capacitive Touch (10 points )
Material :
Aluminum Alloy
Power supply :
DC 12V(AC 100-240V 50/60Hz)
Widescreen :
Yes
Panel type :
TFT
Color :
Black
Application :
embedded/desktop/wall mount
Warranty :
1 Years
Description

7 inch 1000nits sunlight readable embedded touch screen monitor RS232 for touch

Features:

1. Front bezel aluminum alloy brushed metal craft, seamless design, front panel IP65 waterproof.
2. Adopt multi-points PCAP touch panel, high sensitive and fast-response. Covered with 2mm tempered glass for vandalproof.
3. High performance mainboard, 7x24 continuous operation.
4. VGA+HDMI interfaces, RS232 for touch.
5. 1000 nits, sunlight readable.
6. Support wall mounting, embedded mounting, desk stand mouting etc.

Specification

Model:SL07
LCD panel
Panel size 7"
Resolution 1024*600
Aspect ratio 16:9
Support Color 16.7M colors
Brightness (cd/m²) 1000 nits, sunlight readable
Contrast ratio 800:1
View angle 75°/75°/70°/75° (R/L/U/D)
Touch panel
Touchscreen Type Project Capacitive Touch (10 points )
Surface Hardness 7H
Luminousness 90%
Touch Interface RS232 (USB optional)
Touch response time 2ms
Working Life >50 million times
Touch options (5 wires restive touch, IR touch optional)
Signal Ports
VGA 1x VGA
HDMI 1x HDMI
DVI optional
Audio in/out optional
OSD
OSD control Brightness, contrast ratio, auto adjustment, H/V position, language select, etc.
Support languages English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese, etc.
Support OS Windows XP, Windows /7/8/10, Linux, Mac OS X, Android, ect.
Power Supply
External Power Supply AC 100 - 240V, 50-60Hz
Working voltage DC 12V
Power consumption ≤35W
Enclosure
Material Aluminum Alloy bezel+High strength cold rolled steel back case
Color Black, Silver
VESA mounting 75x75mm
IP grade Front panel IP65 waterproof
Operating Environment
Temperature Range operating: -10 to 60°C, storage: -20 to 80°C
Relative humidity operating: 10% to 80%, storage: 5% to 90%
Packing Details
Net weight 1kg
Gross weight 2kg
Product Dimension 21.8*15.5*3.1cm
Packing size 36*26*6cm
Accessories Power adapter, HDMI cable, RS232 touch cable, embedded screws, open frame kits
Other
Mounting embedded mounting screws
wall mounting brackets (optional)
desk stand holder (optional)
Warranty 1 year warranty
Certificates CE, FCC, RoHS

Package

7 Inch 1000 Nits Capacitive Touch Monitor 1024*600 Resolution RS232 For Touch

Certifications

7 Inch 1000 Nits Capacitive Touch Monitor 1024*600 Resolution RS232 For Touch

OEM & ODM

7 Inch 1000 Nits Capacitive Touch Monitor 1024*600 Resolution RS232 For Touch

About Shinho Electronic
7 Inch 1000 Nits Capacitive Touch Monitor 1024*600 Resolution RS232 For Touch


Application

7 Inch 1000 Nits Capacitive Touch Monitor 1024*600 Resolution RS232 For Touch

Application
Smart City
Intelligent Education
Public Transportation
Commercial Terminals
Industrial automation area
Product Stamping and Packaging
