Specifications
Brand Name :
Sihovision
Model Number :
SC104W
Certification :
CE, FCC, RoHS
Place of Origin :
China(Mainland)
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram, Paypal
Product name :
10.4 inch industrial all in one computer
Type :
panel pc
Products status :
Stock
Cpu :
J1900
Memory :
2GB/4GB/8GB
Storage :
32G/64G/128G/256G SSD
Resolution :
800x600
Brightness :
1000+ cd/m2
Interface :
COM, VGA, USB, HDMI
Response time :
2ms
View Angle :
80°/80°/80°/80° (R/L/U/D)
Lan :
10/100/1000Mbps RJ45 LAN
Wifi :
802.11a/b/g/n
Material :
Aluminium alloy
Color :
Black
Touch screen :
4 wire resistive touch
Operating system :
Windows 7/8/10/linux/Ubuntu
Power supply :
DC 12V(AC 100-240V 50/60Hz)
Warranty :
12months
Description

10.4 inch sunlight readable all in one computer 1000 nits embedded industrial pc


Features


1. Sturdy and durable aluminum Alloy front bezel + High strength cold rolled steel back case.
2.Industrial LCD panel, wide viewing angle, high nits, true color.
3. Adopt 4 wires resistive touch screen, high precision, durable, anti-interference.
4. High performance motherboard, 7x24 continuous operation.
5. Full sealed and fanless design, full IP65 waterproof , sunlight readable.

Specification

Model:SC104W
PC
CPU Intel® celeron J1900, 2.0GHz, quad core, fanless
Chipset Intel ValleyView SSA-CUnit
Memory 2G DDR3, (4G optional)
Hard Drive Capacity 32G SSD
Hard Drive Optional SSD: 64G,128GB,256GB
HDD: 500GB,1TB
Graphics CPU Integrated graphics HD Graphics and support 1080p HD photo quality
Audio Realtek ALC662, High Definition Audio (HD), Line in, Line out
Network Onboard Realtek RTL 8111E Gigabit Ethernet controller
Wireless Network WIFI optional
I/O Interface 3 xCOM RS232, 2 xLAN, 4xUSB, 1xVGA
Operation System Support Windows 7/8/10, Linux, Ubuntu, Debian etc.
LCD panel
Panel size 10.4"
Resolution 800x600
Aspect ratio 4:3
Support Color 16.7M colors
Brightness (cd/m²) 1000 nits,sunlight readable
Response time 10ms
Contrast ratio 700:1
View angle 80°/80°/80°/80° (R/L/U/D)
Touch panel
Touchscreen Type 4 wire resistive touch
Surface Hardness 3H
Luminousness 90%
Touch Interface USB
Touch response time 2ms
Working Life >35 million times
Touch options (10 point capacitive touch optional)
Power Supply
External Power Supply AC 100 - 240V
Working voltage 9-24V wide voltage
Power consumption ≤25W
Enclosure
Material Aluminum Alloy front bezel + High strength cold rolled steel back case
Color Black( white, Silver , color can be customized )
VESA mounting 75×75mm
IP-grade IP65
Operating Environment
Temperature Range operating: -10 to 60°C, storage :-20 to 80°C
Relative humidity 5%~95% @ 40° C, non-condensing
Vibration 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
Packing Details
Net weight 4.5KG
Gross weight 6KG
Product Dimension 27×20×4.5cm
Packing size 43×37×17 cm
Accessories Power adapter,waterproof VGA/RS232/LAN/USB cable,touch driver,touch pen
Other
Mounting (options) 1) provide wall bracket for wall-mounting, VESA 100×100mm
2) provide stable metal holder to support the monitor
Warranty 1 year warranty

Drawing

1000 Nits Embedded Industrial Touch Panel PC 10.4 Inch Sunlight Readable 800x600

Package

1000 Nits Embedded Industrial Touch Panel PC 10.4 Inch Sunlight Readable 800x600

Certifications

1000 Nits Embedded Industrial Touch Panel PC 10.4 Inch Sunlight Readable 800x600

OEM & ODM

1000 Nits Embedded Industrial Touch Panel PC 10.4 Inch Sunlight Readable 800x600

About Shinho Electronic
1000 Nits Embedded Industrial Touch Panel PC 10.4 Inch Sunlight Readable 800x600


Application

1000 Nits Embedded Industrial Touch Panel PC 10.4 Inch Sunlight Readable 800x600
Smart City
Intelligent Education
Public Transportation
Commercial Terminals
Industrial automation area
Product Stamping and Packaging
