lithium ion battery charger 67.2v 5A charger using for 60v 20ah 30ah battery
lithium ion battery charger 67.2v 5A charger using for 60v 20ah 30ah battery
lithium ion battery charger 67.2v 5A charger using for 60v 20ah 30ah battery
lithium ion battery charger 67.2v 5A charger using for 60v 20ah 30ah battery
lithium ion battery charger 67.2v 5A charger using for 60v 20ah 30ah battery
lithium ion battery charger 67.2v 5A charger using for 60v 20ah 30ah battery
lithium ion battery charger 67.2v 5A charger using for 60v 20ah 30ah battery
lithium ion battery charger 67.2v 5A charger using for 60v 20ah 30ah battery
lithium ion battery charger 67.2v 5A charger using for 60v 20ah 30ah battery
lithium ion battery charger 67.2v 5A charger using for 60v 20ah 30ah battery
Specifications
Brand Name :
EMC
Model Number :
EMC-400
Certification :
CE, Rosh
Place of Origin :
China
MOQ :
1pics
Price :
USD40-USD48
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
200pics/day
Delivery Time :
5-8 work day
Packaging Details :
carton
Type :
battery charger
Warranty :
1 year
Use :
Lead acid lithium battery , lifepo4 battery pack
Material :
Aluminium alloy
Application :
electric vehicle
Lifetime :
30000 hours
Description

lithium ion battery charger 67.2v 5A charger using for 60v 20ah 30ah battery

lithium ion battery charger 67.2v Specifications:

Input Voltage Range AC 100~240V 50/60HZ
Output Voltage 67.2V
Output Current 5A

lithium ion battery charger 67.2v 5A charger using for 60v 20ah 30ah battery

Features:
1. Charging mode:CC—CV(Constant Current—Constant Voltage)
2. High efficiency and low power consumption
3. Stabilized output and low noice
4. Efficiency(at 100% load): >=80%
5. Operating temperature:0C ~ 45C
6. Storage temperature:-20C ~ 70C
7. Operating humidity:5%~90%RH
8. Rechangeable input plug(Customized)
9. Output Connector: DC, JST, XRL, Alligator Clip,Air plug and so on.

Series Units: 12V / 24V / 36V / 48V /72V @ 20.0A max. 360W Power
No. Output Constant Voltage (CV) Constant Current (CC) Transition / Cut-off Current Hot Sales
Lead Acid Li-MnO2 LiFePO4 Lead Acid (A) Li(A)
1 12V 14.7V 16.8V 14.6V 20A 4 1 48V@5A Lead acid battery charger for golf cart For Ez Go Club Car DS EZGO TXT with RXV Plug 48v@6A Golf Cart Battery Charger 6 Amp YAMAHA* CLUB CAR, Yamaha G19-G22, 2 Pin Plug
2 24V 29.4V 29.4V 29.2V 12A 2.4 0.6
3 36V 44.1V 42.0V 43.8V 8A 1.6 0.4
4 48V 58.8V 54.6V 58.4V 6A 1.2 0.3
5 60V 73.5V 75.6V 73.0V 5A 1 0.25
6 72V 88.2V 84.0V 87.6V 4A 0.8 0.2
Note: Cut-off point for Li battery is 5% of CC, and it can be setted between 3-10%.

lithium ion battery charger 67.2v 5A charger using for 60v 20ah 30ah battery

Gemera Spec:

Compatiable Batteries: Li-ion, Lifepo4, Lead Acid, Lithium Titanate , Ni-mh Titanate

Compatible Battery Lead Acid/LiFePo4/Li-ion/Li-MnO2
Input 90 to 240 VAC 50/60Hz
Output 67.2V 5A
Charge voltage
(Lead Acid)		 73.5V
(Lead acid battery voltage is 60V)		 Float Voltage
(Lead acid)		 57.0V
LiFePo4/3.65V Charge voltage
(S:connect in series)		 65.7V18S
LiFePO4 battery voltage is 3.65V
CC mode
Lithium ion/4.2V
Charge voltage
(S:connect in series)		 67.2V 16S
Li-ion battery voltage is 4.2V <0.6A
LED Indicator Solid Red LED = Charging (0-99%)
Solid Green LED = Fully charged (100%)
Dimension(LxWxH) L180xW90xH65 mm
Weight 1.2Kg
Charging Mode CC/CV, Float/cut-off
Certification UL/cUL / ETL / CE / FCC / RoHS, EN61558 / ETL1310 Approval Standard. Recognized or tested by TUV lab, for more information, please contact us.
Charging Time Cut-off point for Li battery is 8% of CC and it can be set between 3-10%.(charging time:4-5 hours)
Transition for Lead acid charger is 25% of CC.(charging time:6-8 hours)
Protection Over Current, Over Voltage, Over temperature, Short Circuit, Reverse Polarity, shut off or trickle and anti-reverse charge.
Advantage 1). Intelligent cooling fun, controlled by temperatureQuasi-resonant pulse width modulation(PWM),full automatic transition of CC,CV and Float/Cut-off, meet the demands for different Curve.
2). Aluminum case, Robust, Elegant and Reliable.

Protections :

1.Over Current Protection
2. Over Voltage Protection
3. Short circuit protection
4. Reverse input protection

lithium ion battery charger 67.2v 5A charger using for 60v 20ah 30ah battery

Remark (please kindly focus on it)
1.Rechangeable input plug(Customized) , So please confirm it
2.Output Connector: DC, JST, XRL, Alligator Clip,Air plug and so on, So please confirm it
3.For the Necessary quality Certifications, please confirm before ordering
4.For delivery time , We should confirm with each other ,as we do global big business
5.Trust our quality and Recommendation, As we are Global famous Brand EMC

lithium ion battery charger 67.2v 5A charger using for 60v 20ah 30ah battery

Our Service:

1.24-Hours Online. Your offer will be respond promptly.

2.OEM, ODM, Wholesale are welcomed.
3.Please feel free to contact us.

Our Company other hot selling products

lithium ion battery charger 67.2v 5A charger using for 60v 20ah 30ah battery

FAQ

(1). How do we place an order?

Please kindly send us an email specifying the item, quantity, payment
or other specification to place an order.

(2). Your battery can meet CE RoHS requirements?
Our battery are with the certificate of CE/RoHS.

(3). How would the goods be shipped?
We ship via UPS,DHL ,FEDEX and sea transportation normally.

(4). Can you print my picture or logo on the battery cover?
Yes, OEM is available,we can print your picture or logo on the battery case, and you can offer your logo.

(5). What kind of guarantee you give?
Our battery the warranty time is 1year .

More details info,pls kindly feel free to contact with us!
