Lighting Strip EMI Power Line Noise Filter 500VDC Low Current Leakage
Lighting Strip EMI Power Line Noise Filter 500VDC Low Current Leakage
Specifications
Brand Name :
YBX
Model Number :
YB21D1-1A-W(5)
Certification :
cUL, TUV, CQC, CE, ROHS
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P
Supply Ability :
10000 Piece/Pieces per Month Ac 220V General Purpose Noise Filter
Delivery Time :
15-25 days
Packaging Details :
56.5*28.5*22.5cm/CTN; 150pcs/CTN
Name :
Emi Noise Filter
Rated current :
1A-15A
Case :
Metal
Certificate :
cUL TUV CQC CE ROHS
Climatic category :
-25°C~+85°C(25/85/21)
Flammability corresponding to :
UL 94V-0
Description

Lighting Strip EMI Power Line Noise Filter 500VDC Low Current Leakage

250V 10A EMI EMC Power filter with two-stage excellent attenuation compact design small size low current leakage for lighting strip

Technical Specification:

Item Power line Filter
Model Power line Filter YB-D/F
Transfer Function Low Pass
Package Type Surface Mount
Nominal Center Frequency 10K-30MHZ
Insertion Loss 60~90dB
Input Impedance 50Ω
Rated Voltage 115V/250V
Rated Current 1~10A
Environmental Temperature 40°C
Temperature Range 25 / 085 / 21
Operating Frequency 50/60HZ
Line to Line 500VDC
Line to Ground 2250VDC
Maximum Leakage Current 2uA/60HZ, 5uA/50HZ
MOQ Negotiable
Price Negotiable
Lead Time 4~6 weeks

Features:

-- Designed 2 stage enhanced filtering to prevent the power supply may produce interference to the device

-- Various terminal options allow you to select

-- There are a variety of parts and combinations to meet different customer's EMC tests

-- Customized products according to customer's requirements.

Typical Applications:

-- Electrical and electronic equipment

-- Medical equipment

-- Building automation

-- Office automation and datacom equipment

Rule of Nomination:

YB 21 D1 - 10A - Q/W ( 5 )

¦ ¦ ¦ ¦ ¦

circuit case current connection optional


Lighting Strip EMI Power Line Noise Filter 500VDC Low Current Leakage*Q: Fast-on 6.35x0.8mm Lighting Strip EMI Power Line Noise Filter 500VDC Low Current Leakage S: Screw lug Lighting Strip EMI Power Line Noise Filter 500VDC Low Current Leakage W: UL1015 18awg

Electrical schematic:

Lighting Strip EMI Power Line Noise Filter 500VDC Low Current Leakage

Mechanical Dimension(Unit: mm)

Lighting Strip EMI Power Line Noise Filter 500VDC Low Current Leakage


Insertion loss table(In 50ohm system according IEC/CISPR No.17)

Common mode -------- differential mode

Lighting Strip EMI Power Line Noise Filter 500VDC Low Current Leakage

Lighting Strip EMI Power Line Noise Filter 500VDC Low Current LeakageLighting Strip EMI Power Line Noise Filter 500VDC Low Current Leakage

Package Specification:

Lighting Strip EMI Power Line Noise Filter 500VDC Low Current Leakage

Shipment:

---Shipping terms: DHL, UPS, FedEx, TNT, EMS

---Port is Shenzhen or as requests.

Factory Pictures:

Lighting Strip EMI Power Line Noise Filter 500VDC Low Current Leakage

Lighting Strip EMI Power Line Noise Filter 500VDC Low Current Leakage

Lighting Strip EMI Power Line Noise Filter 500VDC Low Current Leakage

Lighting Strip EMI Power Line Noise Filter 500VDC Low Current Leakage

Lighting Strip EMI Power Line Noise Filter 500VDC Low Current Leakage

Lighting Strip EMI Power Line Noise Filter 500VDC Low Current Leakage

Single Phase Filter:
cUL:20190321-E471748
TUV:B0899310001Rev.01
CQC:19001226449
CE:SZAIS180620005-01
ROHS:MMCRHRWM60371744
Three Phase Filter:
cUL:20190325-E502442
ENEC:ENEC-02580
CE:SZAIS180620005-01
ROHS:MMCRHRWM60371744

Our Advantages:

  • We are a listed company. NO:667344, brand guarantee, reliable quality
  • We have UL; cUL; TUV; CQC; CE; ROHS; ISO9001:2015; REACH certification to ensure the product quality
  • We have the relevant professional experimental equipment, so we can provide a free diagnostic conducting test for you.
  • Free EMC rectification technical support and provide free test samples
  • Automation technology, scale production, excellent price
  • Good service, fast delivery!
  • After-sales service: free replacement within three months, free maintenance within 6 years, life-long maintenance
  • Cooperate with the top scientific research laboratory
  • We have a professional R&D team

We Can Provide Professional Solutions For Customers. Please Contact Us For Any Question.
