Class 4 GI Conduit Pipe Electrical Thickness 1.6mm For Wire Protect
Class 4 GI Conduit Pipe Electrical Thickness 1.6mm For Wire Protect
Class 4 GI Conduit Pipe Electrical Thickness 1.6mm For Wire Protect
Class 4 GI Conduit Pipe Electrical Thickness 1.6mm For Wire Protect
Class 4 GI Conduit Pipe Electrical Thickness 1.6mm For Wire Protect
Class 4 GI Conduit Pipe Electrical Thickness 1.6mm For Wire Protect
Class 4 GI Conduit Pipe Electrical Thickness 1.6mm For Wire Protect
Class 4 GI Conduit Pipe Electrical Thickness 1.6mm For Wire Protect
Class 4 GI Conduit Pipe Electrical Thickness 1.6mm For Wire Protect
Class 4 GI Conduit Pipe Electrical Thickness 1.6mm For Wire Protect
Class 4 GI Conduit Pipe Electrical Thickness 1.6mm For Wire Protect
Class 4 GI Conduit Pipe Electrical Thickness 1.6mm For Wire Protect
Specifications
Brand Name :
RIFI
Model Number :
BS4568
Certification :
BS
Place of Origin :
China
MOQ :
1000 pcs
Price :
$0.6-$5/ PCS
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500000 pcs per month
Delivery Time :
15-30 days
Packaging Details :
plastic bag packing
Size :
20mm-50mm
Class :
Class 3 ;Class 4
Thickness :
1.2mm-1.6mm
Length :
3.75 Meter
Standard :
BS4568 BS En61386
Finish :
Pre-Galvanized ; Hot DIP Galvanized
Type :
Steel Gi Conduit
Product Name :
Gi Conduit Hot Dipped Galvanized Steel Class 4
Description

BS Electrical Conduit 20mm 25mm rigid conduit class 4 gi conduit for wire protect



Quick Detail:
BS Electrical Conduit 20mm 25mm rigid conduit class 4 gi conduit for wire protect

BS4568 is British Standard that specifies requirements for electrical conduit systems,it have 2 finish , pre-galvanized called class 3 , hot dip galvanized called class 4
Standard:BS 4568, BS 31 available
Grade:Q195-Q345, Q235, Q195
Thickness:1.2 - 1.6 mm
Section Shape:ROUND
Outer Diameter:20 - 50 mm
Place of Origin:Hunan, China
Application:Structure Pipe
Technique:pre-galvanized
Surface Treatment:galvanized
Special Pipe:EMT pipe; EMT conduit
Length:3.75M
Usage:Electrical Wiring
Quality:Competitive



Specifications:
BS Electrical Conduit 20mm 25mm rigid conduit class 4 gi conduit for wire protect

Outside Diameter Length of Thread
Pipe Size Min Max Wall Thickness(mm) Length(m) Min Max
20 19.7mm 20mm 1.2-1.6 3.75 13mm 15mm
25 24.6mm 25mm 1.2-1.6 3.75 16mm 18mm
32 31.6mm 32mm 1.2-1.6 3.75 18mm 20mm
40 39.6mm 40mm 1.2-1.6 3.75 19mm 22mm
50 49.6mm 59mm 1.2-1.6 3.75 19mm 22mm

Fittings:

BS4568 conduit systems come with a range of fittings and accessories such as couplings,gi conduit bends, malleable iron junction boxes, and gi conduit couplings, all designed to facilitate the installation and routing of electrical wires and cables.

Class 4 GI Conduit Pipe Electrical Thickness 1.6mm For Wire Protect

Class 4 GI Conduit Pipe Electrical Thickness 1.6mm For Wire Protect

Applications:
BS Electrical Conduit 20mm 25mm Rigid Conduit Class 4 GI Conduit for Wire Protect is designed for the protection and routing of electrical wiring in both indoor and outdoor electrical installations. It provides a secure and organized means of housing electrical cables, which helps protect them from physical damage and environmental factors.

BS4568 conduit is typically installed using appropriate fittings and accessories, and it can be fixed to walls, ceilings, or other structural elements using appropriate support brackets or clips.

Class 4 GI Conduit Pipe Electrical Thickness 1.6mm For Wire Protect

Class 4 GI Conduit Pipe Electrical Thickness 1.6mm For Wire Protect

Class 4 GI Conduit Pipe Electrical Thickness 1.6mm For Wire Protect




FAQ
Q1: Are you a trading company or manufacturing company?
A: Both we are, we have 2 production bases and about 10 sourcing factory to meet customer whole line items demand .

Q2:When can I get the quotation?
A1:For regular items within 24 hours; For sprcial items or customize items need a little more time .

Q3: How can I request product samples?
A: The samples are free but courier charge will be collected. Please send us samples list and courier account number.

Q4: How can I request a product catalog?
A: Pls send us your email and we will send you our e catalog ( pdf file ).
The PDF catalog we can send to you by email or WeTransfer.



Our service

1. 24 hours prompt reply by email
2. Other thickness & size also available on request
3. Free samples for your reference
4. Flexible trade term and payment term
5. Excellent after-sale service

Class 4 GI Conduit Pipe Electrical Thickness 1.6mm For Wire Protect
