Semi - Automatic Constant Temperature Liquid Filling Machine Vertical Paste Liquid Heating Mixing Filler
Semi - Automatic Constant Temperature Liquid Filling Machine Vertical Paste Liquid Heating Mixing Filler
Semi - Automatic Constant Temperature Liquid Filling Machine Vertical Paste Liquid Heating Mixing Filler
Semi - Automatic Constant Temperature Liquid Filling Machine Vertical Paste Liquid Heating Mixing Filler
Semi - Automatic Constant Temperature Liquid Filling Machine Vertical Paste Liquid Heating Mixing Filler
Semi - Automatic Constant Temperature Liquid Filling Machine Vertical Paste Liquid Heating Mixing Filler
Semi - Automatic Constant Temperature Liquid Filling Machine Vertical Paste Liquid Heating Mixing Filler
Semi - Automatic Constant Temperature Liquid Filling Machine Vertical Paste Liquid Heating Mixing Filler
Semi - Automatic Constant Temperature Liquid Filling Machine Vertical Paste Liquid Heating Mixing Filler
Semi - Automatic Constant Temperature Liquid Filling Machine Vertical Paste Liquid Heating Mixing Filler
Specifications
Brand Name :
AILUSI
Certification :
CE
Place of Origin :
JIANGSU
MOQ :
1
Price :
800-1500USD
Payment Terms :
L/C, T/T
Supply Ability :
10
Delivery Time :
35
Voltage :
220V/380V
Type :
Filling Machine
Automatic grade :
Semi-Automatic
Application :
Chemical,Beverage,Medical
Packaging material :
Glass,Plastic
Weight :
40kg
Packaging type :
Bottles,Cans
Power :
2KW
Material :
Stainless Steel,SUS304/316(Meet GMP Standard)
Filling range :
30~250ml plastic or glass bottles
Heating method :
Electric Heating Method
Function :
Mixer/Heating/filling
Description

Semi-automatic Constant Temperature Filling Machine Vertical Paste Liquid Heating Mixing Filler

This Machine is suitable for filling materials with high viscosity. It adopts pneumatic filling, electric heating for the hopper and tube, also assembled with mixing functions. The whole machine is with easy cleaning, convenient operation and conforms to GMP standard

  • Item NO.:AFM-ZC

  • Lead Time:10-15 Days

  • Product Orgin:China

  • Shipping Port:Guangzhou Port

  • Product Detail

  • Main Features:

    ● 30L large capacity hopper, hopper and nozzle are removable, easy to clean.(Can be customized)

    ● Real-time stirring of materials to prevent precipitation and solidification.

    ● Water circulation heating, temperature can be set, heating block, anti-corrosion. The inter layer is heated, the operation is not in contact with the material, and the safety is guaranteed.

    ● The whole machine is made of high-quality SUS304 material, and the 320-eye mirror is polished to resist rust and corrosion.

    ● Precise filling nozzle, built-in check valve, wire drawing anti-drip blow-off function, accurate filling without clogging.

    ● The filling volume can be adjusted by hand, and the filling volume scale can be adjusted within the adjustment range.

    ● There are two modes: pedal mode and automatic mode, and the interval time can be set according to the viscosity of different materials.

    ● The air filter device fully filters the impurities and moisture in the gas to ensure the stability and service life of the pneumatic components.

    ● The operating platform can be adjusted according to the height of the bottle, which is more convenient to use.

    ● Movable universal wheel, easy to move. The wheels can be fixed and locked

  • Parameter:

Filling range 5-1000ml
Heating method Water circulation heating Hopper
Capacity General 30L (can be customized)
Material stirring spiral stirring
Filling accuracy ±1%
Filling speed 20-50b/min
Air source pressure 0.4-0.9Mpa
Gross weight 65KG
Product size 75x60x175cm

Application:

Hair cream, Vaseline, Solid balm, Ketchup, Car Beauty Wax, Solid Wax, other materials that need to be heated and melted.

Semi - Automatic Constant Temperature Liquid Filling Machine Vertical Paste Liquid Heating Mixing Filler

Four filling ranges are available: 10-150ml, 25-250ml, 50-500ml, 100-1000ml. please choose products according to your actual needs.

Remark: This equipment needs to be connected to an air compressor, and the air compressor needs to be equipped by yourself or purchased from our company.

Semi - Automatic Constant Temperature Liquid Filling Machine Vertical Paste Liquid Heating Mixing FillerSemi - Automatic Constant Temperature Liquid Filling Machine Vertical Paste Liquid Heating Mixing FillerSemi - Automatic Constant Temperature Liquid Filling Machine Vertical Paste Liquid Heating Mixing FillerSemi - Automatic Constant Temperature Liquid Filling Machine Vertical Paste Liquid Heating Mixing FillerSemi - Automatic Constant Temperature Liquid Filling Machine Vertical Paste Liquid Heating Mixing Filler

Factory:

Semi - Automatic Constant Temperature Liquid Filling Machine Vertical Paste Liquid Heating Mixing Filler

Semi - Automatic Constant Temperature Liquid Filling Machine Vertical Paste Liquid Heating Mixing Filler

Package & Delivery:

To ensure the quality of our service, we will follow the standard package upon delivery:

1. All products before delivery should be tested by assembly and commissioning engineers. Our salesman need to send the tested video to the customer to ensure working well of the machines. Precision parts need to be packed in film or carton.

2. All products are packed in wooden boxes. Firmly fix the edge of the foot of the equipment to adapt the machine to the requirements of loading and uploading.

Our Servers:

After-sales Service: Online support,Video technical support,Free spare parts

FAQ

Q1: Are you a factory or trading company?

A1: We are a factory specialized in Vacuum emulsifying mixer, filling machine, RO water treatment, capping machine and labeling machine…etc for cosmetic, pharmaceutical, chemical equipment over 20 years.

Q2: How does your factory do regarding quality control?

A2: Quality is priority. We always attach great importance to quality controlling from the beginning to the end. We support to inspect machine before shipment.

Q3: What’s the guarantee and the after service if we purchase from you?

A3: All the equipment ordered from us will provide one year guarantee from the delivery date.we could send our engineer to install or fix the machine locally.

Q4: Are your machines difficult to operate? How do you teach us to use the machine?

A4: Our machines are easy to operate, before delivery we will shoot instruction video to introduce machines' functions and to teach you how to use them.

Q5: Can you make the machine according to customers' request?

A5: Yes of course, OEM is acceptable. Most of our machines are customized design based on customer's requirements or situation.
