Specifications
Brand Name :
AILUSI
Certification :
CE
Place of Origin :
JIANGSU
MOQ :
1
Price :
23599-30000USD
Payment Terms :
L/C, T/T
Supply Ability :
10
Delivery Time :
35
Voltage :
380V/220V 50Hz
Automatic grade :
Automatic, Full Automatic
Type :
Filling Machine,Sealing Machine
Application :
Chemical, Food, Medical, plastic tube, laminated tube
Condition :
New
Driven type :
Electric
Packaging type :
Wood
Warranty :
1 Year
Capacity :
1800-4000PCS/H
Filling volume :
5-300ml/PCS(Adjustable)
Function :
Fiiling and Sealing
Weight :
1100 Kg
Machinery Capacity :
4000bph
Tube Length :
50-250(Customizable)
Tube Diameter :
13-50 mm
Tube Material :
Plastic Tube, Multiple Tube
Description

Product Description:

AFS-AL automatic plastic and aluminium tube filling and sealing machine is designed for plastic tube and multiple tube filling and sealing in cosmetic, pharmacy, food stuff, adhesives etc industries. Its operating principle is to put the pipes which is in the feeder hopper into the first service position filling model individually, to invert with rotating disk, to test nomenclature plate in pipe when inverting to the second , to fill with nitrogen gas into pipe in the third, to fill with desired substance in the fourth, then to fix the heating, folding, jamming, number printing, cooling, slivers trimming etc service position, to export the finished products when inverting to the last service position so the twelfth. Every pipe should take such series process to filling, sealing to completion.

Automatic Laminated Tube Printing Machine High Speed Abl/PE Tubes Filling Sealing Lami Tube Sealing Machine

  • Item NO.:AFS

  • Lead Time:30 DAYS

  • Product Orgin:China

  • Shipping Port:Guangzhou Port

  • Payment:EXW, C&F, CIF and etc.

  • Price:$3500/Set

  • MOQ:1

  • Product Detail

Automatic Laminated Tube Printing Machine High Speed Abl/PE Tubes Filling Sealing Lami Tube Sealing MachineAutomatic Laminated Tube Printing Machine High Speed Abl/PE Tubes Filling Sealing Lami Tube Sealing MachineAutomatic Laminated Tube Printing Machine High Speed Abl/PE Tubes Filling Sealing Lami Tube Sealing MachineAutomatic Laminated Tube Printing Machine High Speed Abl/PE Tubes Filling Sealing Lami Tube Sealing MachineAutomatic Laminated Tube Printing Machine High Speed Abl/PE Tubes Filling Sealing Lami Tube Sealing Machine

No.
Item
Description
1
Model
AFS-60
2
Tube material
Plastic tube, Multiple tube
3
Tube diameter
φ13-φ50
4
Tube length
60-250mm(customizable)
5
Filling volume
3-350ml/pc(adjustable)
6
Filling accuracy
≤±1%
7
Product capacity
1800-4000 pcs/h(adjustable)
8
Working pressure
0.55-0.65Mpa
9
Motor power
2KW (380V/220V 50Hz)
10
Heat sealing power
3KW
11
Working Position
12 Pcs. One size one mold.
12
Overall dimension(mm)
L2620×W1236×H1980
13
Machine weight(kg)
1100

* Because the product is updated quickly, please ask us the type of machine before placing an order

Character:

  1. With 9 stations and matching with manipulator, the machine is able to meet different type of tail folding, sealing requirements of aluminum tube, plastic tube and laminated tubes. It is a multi-purpose machine.
  2. The whole procedure of tube feeding, I. marking, tube interior cleaning (optional), material filling, sealing (tail folding), batch number printing, finished products discharging can be performed automatically.
  3. Servo control makes it precise and convenient to adjust the filling amount by touch screen.
  4. According to the different length of the tube, height of tube chamber can be adjusted easily by motor. With external reversal feeding system, makes tube charging more convenient and tidy.
  5. The mechanical linkage photo sensor precision tolerance is less than 0.2mm. The chromatic aberration scope between tube and I. mark is reduced.
  6. Photo-electronic, electric, pneumatic integrative control is applied with the machine. No tube, no filling. It gives an alarm when low pressure occurs. The machine stops automatically if tube error or open the safety door.
  7. Three-layer jacket instant heater with inside air heating, it won't damage the pattern on outer wall of tube and achieves firm and beautiful sealing effect.
  8. The machine has a manipulator of five-fold and three-fold function and can achieve double-sides code print that greatly improves the product quality and the grade of machine.
  9. High-grade liquid crystal display controller matching with buttons for operation that can easily control the stepless speed regulator, parameter setting, constant statistic, pressure instruction and trouble display. The operation is simple and reasonable.

Factory:

Automatic Laminated Tube Printing Machine High Speed Abl/PE Tubes Filling Sealing Lami Tube Sealing Machine

Automatic Laminated Tube Printing Machine High Speed Abl/PE Tubes Filling Sealing Lami Tube Sealing Machine

Package & Delivery:

To ensure the quality of our service, we will follow the standard package upon delivery:

1. All products before delivery should be tested by assembly and commissioning engineers. Our salesman need to send the tested video to the customer to ensure working well of the machines. Precision parts need to be packed in film or carton.

2. All products are packed in wooden boxes. Firmly fix the edge of the foot of the equipment to adapt the machine to the requirements of loading and uploading.

Our Servers:

Ailusi provide Turn-key Project Service to customer.

1. Factory Layout design;

2. Factory Decoration based on GMP standard;

3. Formula of products;

4. Raw material etc;

5. Machine design, whole production line from A to Z;

6. Shipping service, FOB, CFR, CIF etc;

7. Installation service. Training service, Maintenance service.
