Liquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle Filler
Liquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle Filler
Liquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle Filler
Liquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle Filler
Liquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle Filler
Liquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle Filler
Liquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle Filler
Liquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle Filler
Liquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle Filler
Liquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle Filler
Liquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle Filler
Liquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle Filler
Specifications
Brand Name :
AILUSI
Certification :
CE,ISO
Place of Origin :
JIANGSU
MOQ :
1
Price :
800-2000USD
Payment Terms :
D/A, L/C, T/T
Supply Ability :
10
Delivery Time :
35
Voltage :
220V, 220V/50Hz
Type :
Filling Machine
Automatic grade :
Semi-Automatic
Condition :
New
After-sales service provided :
Online support
Filling Material :
Beer, Milk, Water, Oil, Juice, Honey/Lotion/Gel
Machinery Capacity :
20000bph
Power :
2KW
Material :
SUS304 and SUS316L
Power of Paddle Mixing :
0.37kw
Weight :
40kg
Driven Type :
Pneumatic
Filling Accuracy :
99%
Filling Volume :
10-250ml or 50-500ml (Optional)
Air Consumption :
0.05m3/Min
Air Pressure :
0.2-0.8MPa
Filling Speed :
0-30bottles/min
Description

Semi Auto Pneumatic Single Head Bottle Filler Liquid and Paste Cream Jam Sauce Jar Filling Machine

Full pneumatic control cream bottle filling machine vertical semi-autmatic stainless steel paste lotion filler is a pneumatic type filling machine, it through the cylinder's movement of forward and backward to make the piston which is located in the cylinder do reciprocating movement, so as to occur the negative pressure in the preceding chest of the cylinder. All adopt compressed air as the control, so they are quite suitable for the use in the request of anti-explosion environment, has high safety. It's mainly use in filling Water, honey sugar, acid cheese, fruit juice, shower, gear oil, liquid coffee, ink, eye shadow, fluid tea, shampoo, glue, food/paint, washing hand fluid, cream, milk, liquid soap, butter, syrup, plant oil.

SPECIFICATIONS
Filling range
10-250ml, 50-500ml, 100-1000ml and so on
Hopper
35L
Filling speed
20-25 bottles/min(adjustable)
Working Pressure
0.2-0.5 Mpa
Material
SS316L for all contact product parts,Other parts SS304
Performance
Full pneumatic control
Change "manual" and "automatic" filling state

Liquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle Filler

  • Item NO.:AFM-ZC

  • Lead Time:10-15 Days

  • Product Orgin:China

  • Shipping Port:Guangzhou Port

  • Product Detail

Liquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle FillerLiquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle FillerLiquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle FillerLiquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle Filler

Machine Hopper:

* Pressure Cover Type(Including Pressure gauge, air inlet hole).
* Stainless steel to provide pressure for filling the high viscosity liquid. Larger Hopper is ensure the machine can work stably and higher working efficiency.
* If you need to add Mixing(Stirring) is available, any requirements just inquiry me.

Main Features

1) All adopt compressed air as the control, so they are quite suitable for the use in the request of anti-explosion environment, has high safety.
2) Does not appear the phenomenon of static electricity, the leakage of electricity and no need to connect the ground wire.
3) All adopt pneumatic control besides hardware positioning, so they have high filling precision as the precision can be
controlled within 0.5%. (with the greatest amount of filling as standards).


Factory:

Liquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle Filler

Liquid And Paste Cream Jam Sauce Jar Filling Machine Pneumatic Single Head Bottle Filler

Package & Delivery:

To ensure the quality of our service, we will follow the standard package upon delivery:

1. All products before delivery should be tested by assembly and commissioning engineers. Our salesman need to send the tested video to the customer to ensure working well of the machines. Precision parts need to be packed in film or carton.

2. All products are packed in wooden boxes. Firmly fix the edge of the foot of the equipment to adapt the machine to the requirements of loading and uploading.

Our Servers:

We provide Turn-key project service to customer.

1. Factory Layout design;

2. Factory Decoration based on GMP standard;

3. Formula of products;

4. Raw material etc;

5. Machine design, whole production line from A to Z;

6. Shipping service, FOB, CFR, CIF etc;

7. Installation service. Training service, Maintenance service.
