Construction Tools Concrete Poker Vibrator Portable Concrete Vibrator With CE
Construction Tools Concrete Poker Vibrator Portable Concrete Vibrator With CE
Construction Tools Concrete Poker Vibrator Portable Concrete Vibrator With CE
Construction Tools Concrete Poker Vibrator Portable Concrete Vibrator With CE
Construction Tools Concrete Poker Vibrator Portable Concrete Vibrator With CE
Construction Tools Concrete Poker Vibrator Portable Concrete Vibrator With CE
Construction Tools Concrete Poker Vibrator Portable Concrete Vibrator With CE
Construction Tools Concrete Poker Vibrator Portable Concrete Vibrator With CE
Construction Tools Concrete Poker Vibrator Portable Concrete Vibrator With CE
Construction Tools Concrete Poker Vibrator Portable Concrete Vibrator With CE
Construction Tools Concrete Poker Vibrator Portable Concrete Vibrator With CE
Construction Tools Concrete Poker Vibrator Portable Concrete Vibrator With CE
Construction Tools Concrete Poker Vibrator Portable Concrete Vibrator With CE
Construction Tools Concrete Poker Vibrator Portable Concrete Vibrator With CE
Specifications
Place of Origin :
Ningbo,China
Brand Name :
YONGTUO
Certification :
CE,SGS
Model Number :
YT
MOQ :
1 set
Price :
$7/pc
Packaging Details :
carton or up to the customers
Delivery Time :
about 15 days
Payment Terms :
TT or L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
10000 pcs/month
power :
0.25kw ,1.5kw,2.2kw,
Voltage :
220V/380V
Frequency :
50/60HZ
Size :
510*400*510mm
weight :
38kgs
Length of flexible hose :
1-2.5M
Description

Construction Tools Concrete Poker Vibrator Portable Concrete Vibrator with CE


We make the concrete vibrator poker,1m/1.5m/2m/2.5m/3m/4m with larger quantity,more than 100,000 pcs per year. We also supply very best price for it. Welcome your orders.

our target is to serve for clients all over the world and offer the high-quality products and afforable price..we accept OEM service.

Concrete vibrator flexible shaft

1) It is widely used in bridge,port construction,large dams,intensive reinforced concrete wall and other constructional engineer.

2) It is driven by electronic concrete vibrator motor,gasoline concrete vibrator motor or diesel concrete vibrator motor.

3) Maximal working/set efficiency of swing type oscillating stick may reach 25CBM/hour. The motor rotation speed is 3600 rpm, and multi-point vibration speed may reach 12000rpm. It has the advantage of good mechanical performance, stable operation, low noise, good anti-wear performance, and reducing low working costs and labor load. It is widely applied in the world.

Model ZX32 ZX38 ZX45 ZX60
Diameter(mm) 32 38 45 60
Vibrating Frequency(Hz) 184 185 186 187
Outside Dia of Flexible Hose(mm) 30 30 32 36
Dia of Flexible Shaft 10 10 12 13
Packing Way carton carton carton carton
Packing Size(mm) 750*750*55 750*750*55 750*750*70 750*750*55
Length(m) 1to12 1to12 1to12 1to12
Max. Vibration Force(KN) 5.104 5.485 5.932 6.704
Vibrating Amplitude(mm) 1.13 1.18 1. 2 1.28
Available motor or engine Electric Motor, Gasoline Engine, Diesel Engine

Model ZX35 ZX50 ZX70 ZX28
Diameter(mm) 35 50 70 28
Vibrating Frequency(Hz) 183 183 183 183
Outside Dia of Flexible Hose(mm) 30 36 36 30
Dia of Flexible Shaft 10 13 13 10
Packing Way carton carton carton carton
Packing Size(mm) 750*750*55 750*750*55 750*750*70 750*750*55
Length(m) 1to12 1to12 1to12 1to12
Max. Vibration Force(KN) 5.293 6.251 7.157 4.846
Vibrating Amplitude(mm) 1.15 1.21 1.32 1.11
Available motor or engine Electric Motor, Gasoline Engine, Diesel Engine

Construction Tools Concrete Poker Vibrator Portable Concrete Vibrator With CE

Construction Tools Concrete Poker Vibrator Portable Concrete Vibrator With CE

Construction Tools Concrete Poker Vibrator Portable Concrete Vibrator With CE
