Specifications
Place of Origin :
Ningbo,China
Brand Name :
YONGTUO
Certification :
CE,SGS
Model Number :
YT
MOQ :
1 set
Price :
$7 per set
Packaging Details :
carton or up to the customers
Delivery Time :
about 15 days
Payment Terms :
TT or L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
10000 pcs/month
power :
0.25kw ,1.5kw,2.2kw,
Voltage :
220V/380V
Frequency :
50/60HZ
Size :
510*400*510mm
weight :
8kgs
Description

Hand held concrete vibrator/pin type concrete vibrator/concrete needle vibrator

Specifications

Handy concrete Vibrator

Concrete vibrator flexible shaft

1) It is widely used in bridge,port construction,large dams,intensive reinforced concrete wall and other constructional engineer.

2) It is driven by electronic concrete vibrator motor,gasoline concrete vibrator motor or diesel concrete vibrator motor.

3) Maximal working/set efficiency of swing type oscillating stick may reach 25CBM/hour. The motor rotation speed is 3600 rpm, and multi-point vibration speed may reach 12000rpm. It has the advantage of good mechanical performance, stable operation, low noise, good anti-wear performance, and reducing low working costs and labor load. It is widely applied in the world.

Dia25mm,32mm,35mm,38mm and 45mm,with flexible shaft length 1m-2.5m,from 550W-

1100W,easy take,easy handy,easy open,easy use. We export this portable concrete vibrator 4-5 containers per month.

Produce Name: Handheld Portable Concrete Vibrator,800W CONCRETE VIBRATOR 35MM NEEDLE 800W MOTOR FLEXIBLE SHAFT

Power: 550W,750W,800W,1000W,1100W

Voltage: 110-220V 50/60Hz

Lading Speed: 4500r/min

Weight: 2.2KGS

Material: PP+ aluminum+copper

Packing : PP BAG + CORLOR BOX 10PCS IN ONE CARTON

Model ZX32 ZX38 ZX45 ZX60
Diameter(mm) 32 38 45 60
Vibrating Frequency(Hz) 184 185 186 187
Outside Dia of Flexible Hose(mm) 30 30 32 36
Dia of Flexible Shaft 10 10 12 13
Packing Way carton carton carton carton
Packing Size(mm) 750*750*55 750*750*55 750*750*70 750*750*55
Length(m) 1to12 1to12 1to12 1to12
Max. Vibration Force(KN) 5.104 5.485 5.932 6.704
Vibrating Amplitude(mm) 1.13 1.18 1. 2 1.28
Available motor or engine Electric Motor, Gasoline Engine, Diesel Engine

Model ZX35 ZX50 ZX70 ZX28
Diameter(mm) 35 50 70 28
Vibrating Frequency(Hz) 183 183 183 183
Outside Dia of Flexible Hose(mm) 30 36 36 30
Dia of Flexible Shaft 10 13 13 10
Packing Way carton carton carton carton
Packing Size(mm) 750*750*55 750*750*55 750*750*70 750*750*55
Length(m) 1to12 1to12 1to12 1to12
Max. Vibration Force(KN) 5.293 6.251 7.157 4.846
Vibrating Amplitude(mm) 1.15 1.21 1.32 1.11
Available motor or engine Electric Motor, Gasoline Engine, Diesel Engine

Hand Held Concrete Vibrator/Pin Type Concrete Vibrator/Concrete Needle Vibrator

Hand Held Concrete Vibrator/Pin Type Concrete Vibrator/Concrete Needle VibratorHand Held Concrete Vibrator/Pin Type Concrete Vibrator/Concrete Needle Vibrator

You may also interested in concrete vibrator shaft

Contact us:

Sales Manager: Jessica

E-mail:sales@en-machinery.com

Skype: swhome79

www.en-machinery.com

Wechat:0086-13857868709
