R Shape DIP Power Inductor R8*30 Magnetic Bar Unshielded Power Inductor
R Shape DIP Power Inductor R8*30 Magnetic Bar Unshielded Power Inductor
R Shape DIP Power Inductor R8*30 Magnetic Bar Unshielded Power Inductor
R Shape DIP Power Inductor R8*30 Magnetic Bar Unshielded Power Inductor
R Shape DIP Power Inductor R8*30 Magnetic Bar Unshielded Power Inductor
R Shape DIP Power Inductor R8*30 Magnetic Bar Unshielded Power Inductor
Specifications
Brand Name :
TIGER
Model Number :
R8*30
Certification :
ISO, CE,UL, RoHS
Place of Origin :
CHINA
MOQ :
1000PCS
Price :
negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
10000 PCS/Day
Delivery Time :
15-20 Working days
Packaging Details :
Carton: size 28*20*17cm Pallet : size 90*90*95cm (60 cartons)
Name :
R8*30
Shap :
R Shape
Counstruction :
DIP
Operating Temperature :
-40℃~+125℃
Packing :
Plastic bag / Carton
ODM/OEM :
Accepted
Description

High Withstanding Voltage R Shape R8*30 Magnetic Bar Unshielded Power Inductor

Features:

• Use ferrite core,high frequency.

• Low DC resistance, High saturation current.

• Lead free product,RoHs Compliant

• Widely used in switching power supply,power amplifier,output antenna ,filter,Displayer,UPS and etc.

• Available in 367 standard values covering a wide range of inductance and current
• High saturation flux density material is ideal for use in switching regulated power supply applications
• Ideal wherever high current choke values in a small physical size are needed

• Operating Temperature:-40℃∽+125℃

Specifaction :

R Shape DIP Power Inductor R8*30 Magnetic Bar Unshielded Power Inductor

Part No. A B C D
Max ±1 ±0.5 ±0.15
RAR0830-4R7M 12.2 22.5 9.85 1.8
RAR0830-5R6M 11.8 22 9.65 1.6
RAR0830-6R8M 11.6 21 9.45 1.4
RAR0830-8R2M 11.2 21 9.35 1.3
RAR0830-100M 10.9 22 9.25 1.2
RAR0830-150M 10.6 23 9.05 1
RAR0830-220M 10.2 22.5 8.85 0.8


Application:

R Shape DIP Power Inductor R8*30 Magnetic Bar Unshielded Power Inductor

TIGER designs and manufactures a wide range of products for critical applications in various industries, including but not limited to:

• Automotive

• Consumer Electronics

• Industrial

• Medical

• Military & Aerospace

• Telecommunications

We are uniquely positioned to offer the highest quality products for critical applications as well as cost effective products for price sensitive applications.

Packing:
R Shape DIP Power Inductor R8*30 Magnetic Bar Unshielded Power Inductor
FAQ
1. Q: Can I get some samples?
A: Yes, sample order is available for quality check and market test.
2. Q: What's the delivery time?
A: Sample order needs 7 days. Formal order needs 15-20 days.
3. Q: What's your payment terms?
A: We usually accept T/T at sight as the main payment terms, and other payment can also be negotiated.
4. Q: Do you have the prodcts in stock?
A: Yes,we will keep some general ones in stock.
5. Q: Can I mix different models in one container?
A: Yes,different models can be mixed up.
6. Q: Do you customize for customer or accept OEM Orders ?
A: Yes,we provide designing and customizing services. OEM orders are also accepted.
R Shape DIP Power Inductor R8*30 Magnetic Bar Unshielded Power Inductor
