EE-64 5000W Single PCB Planar Power Transformer Customized Low Profile Power Inductor
EE-64 5000W Single PCB Planar Power Transformer Customized Low Profile Power Inductor
EE-64 5000W Single PCB Planar Power Transformer Customized Low Profile Power Inductor
EE-64 5000W Single PCB Planar Power Transformer Customized Low Profile Power Inductor
EE-64 5000W Single PCB Planar Power Transformer Customized Low Profile Power Inductor
EE-64 5000W Single PCB Planar Power Transformer Customized Low Profile Power Inductor
Specifications
Brand Name :
Tiger
Model Number :
TG-EE64 5000W
Certification :
ISO, CE,UL, RoHS
Place of Origin :
China
MOQ :
1000pcs
Price :
negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
10000pcs/day
Delivery Time :
around 20 days
Packaging Details :
Carton/Pallet
Coil Structure :
Toroidal
Type :
EE
Frequency :
High frequency
Coil Number :
Auto transformer
OEM :
Accepted
Quality :
100% test
Description

EE-64 5000W Low-profile Single PCB Planar Transformer Customized Specifications Are Welcome


Features:

  • Widely used in switch power supply,ups power,pc power and many electronic equipment
  • Wide range of application
  • High working frequency
  • High power of working voltage
  • profile planar transformer

  • Use EE64 Planar transformer magnetic core,multilayer pcb technique

  • Use for DC/DC module power ,max output power 5000W
  • Working frequency: 80k∽200K
  • withstand voltage between secondary coils:1.0~3.5KVDC

  • Working temperature Range:-40℃-85℃

  • Weight:≤470g



Specifaction :

EE-64 5000W Single PCB Planar Power Transformer Customized Low Profile Power Inductor

PART NUMBER Pri to Sec Ratio Primary N1(P1-P2)

Sec

(N2+N3)
N1:(N2+N3)

Inductance

( Min)

LeakageInductance

(Max)

DC Resistance

(Max)
EE64T306021 6:(1+1) 2µH 1.0µH 6.7mΩ 0.08mΩ+0.08mΩ

EE-64 5000W Single PCB Planar Power Transformer Customized Low Profile Power Inductor

Application:
EE-64 5000W Single PCB Planar Power Transformer Customized Low Profile Power Inductor
TIGER designs and manufactures a wide range of products for critical applications in various industries, including but not limited to:
· Automotive
· Consumer Electronics
· Industrial
· Medical
· Military & Aerospace
· Telecommunications
We are uniquely positioned to offer the highest quality products for critical applications as well as cost effective products for price sensitive applications.
Packing:
EE-64 5000W Single PCB Planar Power Transformer Customized Low Profile Power Inductor
FAQ
1. Q: Can I get some samples?
A: Yes, sample order is available for quality check and market test.
2. Q: What's the delivery time?
A: Sample order needs 10 days. Formal order needs around 20 days.
3. Q: What's your payment terms?
A: We usually accept T/T at sight as the main payment terms, and other payment can also be negotiated.
4. Q: Do you have the prodcts in stock?
A: Yes,we will keep some general ones in stock.
5. Q: Can I mix different models in one container?
A: Yes,different models can be mixed up.
6. Q: Do you customize for customer or accept OEM Orders ?
A: Yes,we provide designing and customizing services. OEM orders are also accepted.
EE-64 5000W Single PCB Planar Power Transformer Customized Low Profile Power Inductor
