3.5kw 5.5kw 220vac Off Grid Hybrid Solar Inverter Solar Charge Controller Mppt 3000w 5000w Solar Inverter
3.5kw 5.5kw 220vac Off Grid Hybrid Solar Inverter Solar Charge Controller Mppt 3000w 5000w Solar Inverter
3.5kw 5.5kw 220vac Off Grid Hybrid Solar Inverter Solar Charge Controller Mppt 3000w 5000w Solar Inverter
3.5kw 5.5kw 220vac Off Grid Hybrid Solar Inverter Solar Charge Controller Mppt 3000w 5000w Solar Inverter
3.5kw 5.5kw 220vac Off Grid Hybrid Solar Inverter Solar Charge Controller Mppt 3000w 5000w Solar Inverter
3.5kw 5.5kw 220vac Off Grid Hybrid Solar Inverter Solar Charge Controller Mppt 3000w 5000w Solar Inverter
Specifications
Place of Origin :
china
MOQ :
negotiated
Price :
negotiated
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram, MoneyGram
Delivery Time :
negotiated
Input Voltage :
230VAC
Output Voltage :
230VAC
Output Frequency :
50Hz/60Hz
Size :
370*375*1147mm
Communication :
USB/RS485
Rated power :
5500W
Description

3.5kw 5.5kw 220vac Off Grid Hybrid Solar Inverter Solar Charge Controller Mppt 3000w 5000w Solar Inverter

Specification
MODEL
PMD VM II 3500-24
PMD VM II 5500-48
Rated
3500VA/3500W
5500VA/5500W
INPUT
Voltage
230VAC
Selectable Voltage Range
170-280VAC(For Personal Cpmputers):Computers):20ms(ForHomeAppliances)
Frequency Range
50Hz/60HZ(Auto sensing)
OUTPUT
ACVoltage Regulation(Batt.Mode)
230VAC+5%
Surge Power
7000VA
11000VA
Efficiency(Peak)
up to 93.5%
Transfer Time
10ms(ForPersonalComputers): 20ms(ForHomeAppliances)
Waveform
Pure sine wave
BATTERY
Battery Voltage
24VDC
48VDC
Floating Charge Voltage
27VDC
54VDC
Overcharge Protection
33VDC
63VDC
SOLAR CHARGER&AC CHARGER
Maximum PV Array Open Circuit Voltage
500VDC
500VDC
Maximum PV Array Power
5500W
5500W
MPPT Range @ Operating Voltage
120~450VDC
120~450VDC
Maximum Solar Charge Current
100A
100A
Maximum AC Charge Current
80A
80A
Maximum Charge Current
100A
100A
PHYSICAL
Dimension,D*W*H(MM)
100x300x440
Net Weight(kgs)
9
10
Communication interface
USB/RS232
ENVIRONMENT
Humidity
5% to 95%Relatve Humidity (Non-condensing)
Operating Temperature
-10°C to 50°C
Storage Temperature
-15°C to 60°C

3.5kw 5.5kw 220vac Off Grid Hybrid Solar Inverter Solar Charge Controller Mppt 3000w 5000w Solar Inverter

FAQ
Q1: Are you a factory?
A1: Yes, PMDis a factory and manufacturer.

Q2:Can you provide OEM and ODM services?
A2: Yes, we can. MOQ 100pcs for OEM and ODM to make sure your prices be more competitive in the market.

Q3:How to control the quality of your products?
A3: Our company has got the ISO9001 approval. Except the chips and packaging box outsourced,
the other parts are researched and produced by ourselves. Product Quality is fully controlled by ourselves
from beginning to end. 100% QC to make sure product in high-quality and low-defect before shipping.

Q4:What kind of certificates did the products have obtained?
A4: Most of our products certified with UL, FCC, PSE, CB, CE ,
which can cover the import requirements of most countries.
