Specifications
Place of Origin :
Guangdong, China
MOQ :
negotiated
Price :
negotiated
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
negotiated
Cycle life :
≥6000 80% DOD
Battery Type :
LiFePO4
Voltage :
51.2V
Certification :
Ce/RoHS/MSDS/UN38.3/ISO9001
warranty :
5 years
Description

48V 100ah 200ah 5kwh 10kwh sodium ion sodium-ion lithium battery sodium-ion-battery batterie de power wall for ESS

Product Description
Model
PMD-1
PMD-2
PMD-3
Battery Type
LiFePO4(LFP)
Nominal Voltage(v)
51.2V
51.2V
25.6V
Nominal Energy(kWh)
5.12kWh
10.24kWh
5.12kWh
Nominal Capacity(Ah)
100Ah
200Ah
200Ah
Design Years
15 Years
Size
520×600×165mm
570×730×165mm
505×450×185mm
Weight
≤55kg
≤95kg
≤55kg
Cycle Life
≥6000 cycles
Operating Voltage Range
40V~58.4V
20V~29.2V
Charging Voltage
DC 58.4V
DC 29.2V
Operating Temperature
-10~55℃
Warranty
10 Years (2 Years free warranty, rest 8 years pay actual repair costs)
Charge/Discharge Current(A)
Same Port Max. 100A
Internal Resistance
≤40mΩ
Self-Consumption
≤2.5W
Rated Voltage
51.2V
25.6V
Balance current
30~65(MA)
Communication Method
CAN/RS485/RS232(Optional)
Information Storage
500 Strip
Limiting
10/20A(Optional)

Solar Energy Storage System(Off Grid Solar System&Hybrid Solar System)

Lithium LiFePO4 Battery 51.2V 5.12kWh/10kWh/15kWh wall battery are most popular and widely used in solar storage system(Off Grid Solar System&Hybrid Solar System ). Wall battery can be connected in Parallel to store more energy.

48V 100ah 200ah 5kwh 10kwh Sodium Ion Sodium-Ion Lithium Battery Sodium-Ion-Battery Batterie De Power Wall For ESS

Company Profile

Guangzhou PMD New Energy Co., Ltd. are a Professional Manufacturer of LiFePO4, Lithium Ion, Li-Polymer, Ni-MH Battery Packs and Accessories. After more than 10 years learning and exploration, we’ve grown to a company with complete R&D team and quality inspection system. We focus on battery solutions for Energy Storage System, Solar Street Lighting, Electric Vehicle, Telecom and UPS etc.

FAQ

Q1: Can I get free sample?

A1: Generally we don't provide free sample, but we can return sample cost when the buyer plant a bulk order.

Q2: How should I pay?

A2: You can pay via T/T,L/C at sight, PayPal, Western Union, Cash etc., 100% T/T in advance for samples. For large quantities, 30% T/T in advance as soon as order confirmed and the balance before shipping via T/T or L/C etc. If you prefer other payment terms, please contact us freely.

Q3: What is delivery time if we place an order?

A3: It depends order quantities. Usually, we can deliver goods within 3 -5 working days for small orders, for more QTY. order, let's confirm when you place offical order.

Q4: Are your factory or trading company?

A4: We are proffesional lithium-ion rechargeable batteries manufacturer with our own factory and brand. We provide all kinds of OEM/ODM services for clients around globe.

Q5.What is your warranty?

A5: We offer 5 years warranty for all our battery pack.we ensure at least 6000 cycle life for the LiFePO4 battery pack, which means,after 6000@80% DOD,there will still around 60% capacityt left.You can use it for at least 5 years for normal 1 time charge and discharge everyday.

Q6.Can we put different LiFePO4 battery pack in parallel or series by ourself?

A6: Yes. The battery can be put in parallel or series by customers. But there are few tips we need to pay attention:

1> Make sure the voltage of each battery are same before put inparallel. If they are not same, charge them to the same rate;

2> Do not put discharged battery and undischarged battery in parallel. This may reduce the capacity of the whole battery pack; 3> Do not put the batteries in series.

4> If you are not professional in parallel batteries, please don't handle the battery by yourself. It may cause danger and hurt the cycle life of battery;
