5kw 10kw Home Energy Storage Systems 20kwh All In One Solar System Inverter 48v 200ah Battery 10kw Lithium Battery
5kw 10kw Home Energy Storage Systems 20kwh All In One Solar System Inverter 48v 200ah Battery 10kw Lithium Battery
5kw 10kw Home Energy Storage Systems 20kwh All In One Solar System Inverter 48v 200ah Battery 10kw Lithium Battery
5kw 10kw Home Energy Storage Systems 20kwh All In One Solar System Inverter 48v 200ah Battery 10kw Lithium Battery
Specifications
Place of Origin :
Guangdong, China
MOQ :
negotiated
Price :
negotiated
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
negotiated
Load Power (W) :
5kw, 10kw, 15kw
Controller Type :
MPPT, PWM
Warranty :
5 Years
Output Frequency :
50Hz/60Hz
Battery Type :
Lithium Ion
Description

5kw 10kw Home Energy Storage Systems 20kwh All In One Solar System Inverter 48v 200ah Battery 10kw Lithium Battery

Product parameters
Item
Product Parameter
Model
48100LS
48200LS
48300LS
Batteries materials
Lithium iron phosphate
Series parallel mode (S series, P parallel)
16S1P
16S1P
16S1P
Nominal voltage
51.2V
51.2V
51.2V
Nominal capacity
100Ah
200Ah
300Ah
Size(mm)
588*195*430/module
588*195*430/module
588*195*430/module
Weight
48KG
96KG
144KG
Color
Optional
Parallel support
Parallel terminals are supported
Output port mode
terminal
Charging way
CC/CP/VP
Charging current0.2C(standard)
0.2C(standard)
Maximum charging current
Max1C @25℃
Charge cut-off voltage
58.4V
Discharge way
CC/CP/VP
Discharge current
1C
Maximum discharge current
Max1C @25℃
Discharge cut-off voltage
44.8V
According to
LCD
Communication interface
RS485/RS232/CAN
Charging operating temperature
charging0~+50℃
Discharge operating temperature
discharge-20~+55℃
Warranty
5 years
Inverter
3.5/5.5KW
Scope of application
hospital, bank data center, wall-mounted home, enterprise energy storage backup power supply, wind complementary system, office,
military, base station and other uninterrupted energy storage power supply.

OUR ADVANTAGE
  • We are a professional energy storage battery manufacturer, can provide exclusive customized services.
  • Strict cell volume separation technology, from the source to improve product quality.
  • Our products can be compatible with 95% brand inverter, your choice is more.
  • We have a professional research and development team, BMS protection plate performance is better.
  • We use high current to carry out aging test on products, which makes it easier to detect problems in advance.

5kw 10kw Home Energy Storage Systems 20kwh All In One Solar System Inverter 48v 200ah Battery 10kw Lithium Battery

Company Profile
Guangzhou Pei Mengdan new energy Technology Co., LTD is focusing on the production of Li-ion battery energy, designing and marketing of battery, solar generator, energy storage system, telecom backup battery, UPS, solar street light battery and customized battery pack services.With more than 10 national and international patents, our products have already been certified with IEC, UL, CE, FCC, ROHS, UN38.3, MSDS, PSE, shipping report etc.

5kw 10kw Home Energy Storage Systems 20kwh All In One Solar System Inverter 48v 200ah Battery 10kw Lithium Battery

Application

5kw 10kw Home Energy Storage Systems 20kwh All In One Solar System Inverter 48v 200ah Battery 10kw Lithium Battery

FAQ

Q1: What is your quality control process?
A1: Our factory has ISO9001 certification, from incoming materials to production, and then to delivery, there are corresponding QC control. Battery cells will be divided before assembly, and aging test will be conducted before delivery.

Q2: Do you accept ODM/OEM orders?
A2: Yes, we can accept OEM/ODM, you can change the logo and function as you want.

Q3: Can I get the pre-production sample?
A3: Yes, we will send you sample for approval first, after you confirm, then we will start mass production order.

Q4: Can battery size customized available?
A4: Yes, please send up the capacity and max battery size, so that we can search our model for you.

Q5: How to proceed an order?
A5: Firstly, let us know your requirements or application. Secondly, we quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order. Fourthly we arrange the production
