The advantages of high-speed injection molding machine and ordinary machine!

With the increasing use of high-speed products, it is becoming a high-speed injection molding machine that is of concern to business friends.

So what is the difference between a high-speed injection molding machine and a general injection molding machine? This topic has been discussed.

The actual analysis of high-speed injection molding machine is hydraulic and electric motor mixing, the ordinary injection molding machine is pure hydraulic injection molding machine, and the hydraulic injection molding machine relies on hydraulic oil to drive the relative running speed is slow, and the high-speed injection molding machine uses the servo motor to realize the opening and closing mode. Ejection demoulding, raw material injection and storage, etc., the injection speed is faster and the position control is more precise, which greatly improves the production efficiency. But now the servo electric injection molding machine has only machines with clamping force below 650 tons.

The difference between high-speed injection molding machine and ordinary injection molding machine:

1. The molding process of the ordinary injection molding machine is: mold clamping – injection – cooling – storage – mold opening – tray – gap time.

2. The high-speed injection molding machine is highly efficient, and the high-speed injection molding machine adopts three-axis linkage, which is commonly referred to as three-circuit. The molding process is: mold clamping – injection – cooling – mold opening (synchronous mold, storage) – gap time. For example, a molding machine with a common injection molding machine has a molding time of 10 seconds, while the Lisong high-speed injection molding machine uses the principle of three-axis linkage, the molding time is greatly shortened by about 6 seconds, minus two small steps, and the time is increased by about half. .

3, high-speed injection molding machine environmental protection, the standard pump used in ordinary injection molding machine, the pollution in power, hydraulic oil and noise is relatively large.

to sum up

The high-speed injection molding machine uses a hybrid of hydraulic and servo motors. The advantages of the servo hydraulic system are as follows: The implementation of the soft start mold will not affect the power network and avoid voltage and electric radiation pollution. It can effectively prevent the oil temperature from being too high and the temperature drop is good. Greatly reduce the replacement rate of hydraulic oil. Due to the better click and power system gear pump, the servo hydraulic system can greatly reduce the machine operation and production noise, and can better improve the working environment. The high-speed injection molding machine can save 60~70% of the total power of the ordinary injection molding machine, greatly reducing the cost and saving resources for customers.
