Automatic Hydraulic Injection Molding Machine 11.65KW Heater Power
Automatic Hydraulic Injection Molding Machine 11.65KW Heater Power
Automatic Hydraulic Injection Molding Machine 11.65KW Heater Power
Automatic Hydraulic Injection Molding Machine 11.65KW Heater Power
Automatic Hydraulic Injection Molding Machine 11.65KW Heater Power
Automatic Hydraulic Injection Molding Machine 11.65KW Heater Power
Automatic Hydraulic Injection Molding Machine 11.65KW Heater Power
Automatic Hydraulic Injection Molding Machine 11.65KW Heater Power
Specifications
Brand Name :
HAIJIA
Model Number :
HJF 240
Certification :
CE ISO9001
Place of Origin :
China (Mainland)
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000set/sets per year
Delivery Time :
20-30days
Packaging Details :
Standard Export Package for Injection Machine
Max.Pump Pressure :
16
Pump Motor Power :
18.5
Heater Power :
11.65
Machine Dimension :
5.4*1.5*2
Machine Weight :
7
Oil Tank Capacity :
340
Description
SPECIFICATION HJF240
Screw Type A B C
Screw Diameter Mm 50 55 60
Screw L/D Ration L/D 22.2 20 18.2
Shot Size(Theoretical) cm3 508 593 706
Injection Weight(PS) g 462 534 642
Injection Rate g/s 148 179 202
Injection Pressure MPa 180 160.8 128
Screw Speed rpm 0~180
Clamping Force KN 2400
Opening stroke Mm 490
Space Between Tie Bars mm 530*510
Max.Mold Height mm 530
Min.Mold Height mm 200
Ejector Stroke mm 165
Ejector Tonnage KN 70
Max.Pump Pressure MPa 16
Pump Motor Power KW 18.5
Heater power KW 11.65
Machine Dimension(L*W*H) M 5.4*1.5*2
Machine weight T 7
Oil Tank Capacity L

340

Automatic Hydraulic Injection Molding Machine 11.65KW Heater Power

Characteristic

The machine use the high-performance servo dynamic control system, the oil pump as the power source, having the characteristics as follow: high response,saving energy, low noise, high-control precision, and have the breakthrough in the prefect connection of the electrical servo and hydraulic drive system.

High Energy saving

Under the ideal working state, Power consumption is 40% less than that of variable displacement pump and 70% less than that of fixed displacement pump, save the cost effectively.

High precision

Precise control of low pressure & low flow, repeating precision is less than 0.5%. Weight error of the products is 0.4%~0.7%, with semi-close loop system nearly.

Low noise

Different from ordinary fixed pump injection molding machine, servo power-saving injection molding machine is working only when necessary. And working noise is less than 70dB, will be much quieter for your working area.

Automatic Hydraulic Injection Molding Machine 11.65KW Heater Power
