High Performance Plastic Injection Molding Machine , Plastic Mould Injection Machine
High Performance Plastic Injection Molding Machine , Plastic Mould Injection Machine
High Performance Plastic Injection Molding Machine , Plastic Mould Injection Machine
High Performance Plastic Injection Molding Machine , Plastic Mould Injection Machine
High Performance Plastic Injection Molding Machine , Plastic Mould Injection Machine
High Performance Plastic Injection Molding Machine , Plastic Mould Injection Machine
Specifications
Brand Name :
HAIJIA
Model Number :
HJF 240
Certification :
CE ISO9001
Place of Origin :
China (Mainland)
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000set/sets per year
Delivery Time :
20-30days
Packaging Details :
Standard Export Package for Injection Machine
Injection Rate :
179
Injection Pressure :
160.8
Screw Speed :
0-180
Max.Pump Pressure :
16
Pump Motor Power :
18.5
Heater Power :
11.65
Description

High performance and high accurate injection molding machine for plastic plant

1.Hydraulic closed loop and motor speed closed loop is realized by control system with the features of high repetition, high linearity, high linearity, high efficiency, high precision, fast response, low rejection rate,low noise, low vibration and long service life, High-rigidity template design with T shot andordinary threaded hole facilitates the mold installtion. Oil filter equipment of high performance and high precision can keep the grease within NAS8. Color control system is adopted.

2. Injection Unit Features

2.1 Injection unit adopts duble-cylinder design, more higher injection pressure, more simpler structure and lower malfunction rate.

2.2 Enlarged-cylinder, adopting two -cylinder design,effectively prevent the adhesive-material leaking phenomenon because of the machine vibration or other reasons when the nozzle is under high-speed operation.

2.3 Adopting graphite bush, improving the wear-resistance, reducing the frequency of using lubrication oil effectively improve the cleanness of the injection part.

2.4 Injection cylinder adopts low-frictional seals, improving the response rate and improve the stability under the complicated processes of injection.

2.5 Bridge-style design, for different L/D plastic parts.

High Performance Plastic Injection Molding Machine , Plastic Mould Injection Machine

SPECIFICATION HJF240
Screw Type A B C
Screw Diameter Mm 50 55 60
Screw L/D Ration L/D 22.2 20 18.2
Shot Size(Theoretical) cm3 508 593 706
Injection Weight(PS) g 462 534 642
Injection Rate g/s 148 179 202
Injection Pressure MPa 180 160.8 128
Screw Speed rpm 0~180
Clamping Force KN 2400
Opening stroke Mm 490
Space Between Tie Bars mm 530*510
Max.Mold Height mm 530
Min.Mold Height mm 200
Ejector Stroke mm 165
Ejector Tonnage KN 70
Max.Pump Pressure MPa 16
Pump Motor Power KW 18.5
Heater power KW 11.65
Machine Dimension(L*W*H) M 5.4*1.5*2
Machine weight T 7
Oil Tank Capacity L 340
