Feature

1. Support negative – voltage display

2. Single series range 0.1V-6V

3. Measurement accuracy 0.05%±3MV

4. Support for mixed insertion (without starting with B-)

5. Automatically identify the number of battery series

6. Display the highest voltage, the lowest voltage, and the maximum differential voltage between series

7. TypeC port power supply

8. Color LCD display with 1S to 24S battery pack measurement

To measure potential-difference, or voltage, a voltmeter must be connected betweentwo points at different potentials. In other words, a voltmeter must always be connected in parallel with the part of the circuit under test.

It can be a voltmeter that measures voltage or an ammeter that measures current, an ohmmeter that measures resistance or an Battery string voltage measuring instrument to measure continuity, temperature and more.

Voltage measuring instrument display measurements as a number and offer the most reliable readings.

Use Steps

1. Use the TypeC power port or DC power supply to the power.

2. Press and hold the K1 button for 10 seconds to automatically switch to the English interface.

3.. Select the detection port according to its own interface, and then you can check whether the voltage difference is normal.

Note:
1. The 2.0mm pin and 2.54mm pin of the tester are designed for parallel input and can only be connected to one set of batteries, and cannot be touched with metal conductors.

2. The tester does not come with cables! Each customer's needs are different, and the cables used are also different!

3. The hardware configurations of the Chinese and English versions are exactly the same, except for the display interface. Foreign users please purchase the English version.

4. This product is only used to test the voltage of each battery string and has no balancing function!

5. This product has a one-year warranty! If there is any damage caused, you will have to pay the return shipping fee!

6. The original intention of the tester is to test the assembled battery pack and test the voltage of each string. If it is modified for other purposes, we will not provide technical support.

7. If you do not have professional electronic and electrician skills, it is not recommended to purchase this product.

8. The adapter board can be plugged into the tester and is compatible with battery testing purposes of different series numbers (because the adapter pins will be crushed during transportation, we do not solder the pins before shipping)
