Mini Portable Rated 165A MMA/ 175A TIG IGBT Inverter Welder
Mini Portable Rated 165A MMA/ 175A TIG IGBT Inverter Welder
Mini Portable Rated 165A MMA/ 175A TIG IGBT Inverter Welder
Mini Portable Rated 165A MMA/ 175A TIG IGBT Inverter Welder
Mini Portable Rated 165A MMA/ 175A TIG IGBT Inverter Welder
Mini Portable Rated 165A MMA/ 175A TIG IGBT Inverter Welder
Mini Portable Rated 165A MMA/ 175A TIG IGBT Inverter Welder
Mini Portable Rated 165A MMA/ 175A TIG IGBT Inverter Welder
Mini Portable Rated 165A MMA/ 175A TIG IGBT Inverter Welder
Mini Portable Rated 165A MMA/ 175A TIG IGBT Inverter Welder
Mini Portable Rated 165A MMA/ 175A TIG IGBT Inverter Welder
Mini Portable Rated 165A MMA/ 175A TIG IGBT Inverter Welder
Specifications
Brand Name :
GENWELD
Model Number :
TIG200A
Certification :
CE
Place of Origin :
CHONGQING
MOQ :
50 SETS
Payment Terms :
L/C, T/T
Supply Ability :
10000 sets per month
Delivery Time :
20 work days
Packaging Details :
450*270*345mm
Input voltage :
AC220V
Welding current :
MMA:20-165A TIG:15-175A
Rod dia. :
MMA:2.5-3.2mm, Tungsten:φ1.0～3.0
Insulation Class :
F
Protection Class :
IP23
TIG Gun :
QQ-150
Neight weight :
6.4kg
Packing dimension :
450*270*345mm
Description

GENWELD TIG200A Argon ARC welding Machine(TIG)

Features:

• The front panel is equipped with overheat-protection and over-current protection indicators. The current display is used to show the current data accurately. The acceptable input voltage range 130 - 260V.

• Three-layer PCB structure ensures the performance of the welding machine. Especially, the power supply board is more safe and stable.

• Hi-speed running fan with more optimized heat sink channel design, which makes the heat dissipation effect is 30% higher than the same type of inverter welding machine.

• Full bridge Inverter IGBT dual modules, large output voltage.

• Large capacitors are more flexible and support to connect with generator use.

• The whole series of products with hot arc starting, arc force, and anti-sticking functions. Easy to start the arc, low-pressure drop, comfortable operation.

• New dust-proof design, nice appearance, more cost-effective, more portable, and lighter.

Application field

• It’s widely used for many kinds of metal welding, like carbon steel, stainless, iron and etc.

Specification sheet

Model TIG200A
Input voltage (V) AC220V
Rated input current(A) MMA:34 / TIG:23
Current range(A) MMA:20-165A TIG:15-175A
No load voltage(V) 65
Duty cycle@40℃ 60% 100%
Max. output current(A) MMA:165 TIG:175 MMA:128 TIG:135
Max.output Voltage(V) MMA:26.6 TIG:17 MMA:25.1 TIG:15.4
Max. output power(W) MMA:4389 TIG:2975 MMA:3212.8 TIG:2079
Rated output current(A) MMA:165 TIG:175 MMA:128 TIG:135
Rated output Voltage(V) MMA:26.6 TIG:17 MMA:25.1 TIG:15.4
Welding rod(mm) Tungsten:φ1.0～3.0
Electrode(mm) for MMA 2.5/3.2
Insulation Class F
Protection Class IP23
Dimension (mm) 375*150*310
Net weight (kg) 6.4
Packing Dimension(mm) 450*270*345
Gross weight(kg) 9.1
TIG Gun(m) QQ-150
Ground Cable+Clamp(m) 1.5(copper)
Power cable+Plug(m) 1.5

Mini Portable Rated 165A MMA/ 175A TIG IGBT Inverter Welder

Mini Portable Rated 165A MMA/ 175A TIG IGBT Inverter Welder

Mini Portable Rated 165A MMA/ 175A TIG IGBT Inverter Welder
